Trending Menus
The Trending Menus allow for setting up and managing onboard
trending of up to 30 data points within the controller . This data
can then be exported to an SD card . The trending memory will
begin over-writing the oldest existing data in the controller's
memory when the allocated trending memory fills up. If an
SD card is installed in the controllers SD card reader slot, an
automatic export of the data will occur every night at midnight .
Table 30: Trending Menu
Item Display
Default Setting
Name
Trending Ena=
No
Apply Chgs=
No
Sample Time=
300s
TrendOnOff=
Off
AutoExpTime=
1440m
Export Data=
No
Clear Trend=
Done
TrendFull=
Wrap
DefaultTrend=
No
Trending Ena is an adjustable item which enables and
disables the on board trending function .
Apply Changes is an adjustable item which must be set to
make changes to trending point definitions and sampling rate
take effect.
Sample Time is an adjustable item used to the sampling rate
for trending data points .
TrendOnOff is an adjustable item which starts and stops the
on board trending function .
AutoExpTime is the length of time a trend is to be captured
Export Data is an adjustable item which initiates a manual
export of the current on board trend data to an SD card .
Clear Trend is an adjustable item used to either clear only the
current trend data or the entire trend configuration.
TrendFull is a writable input that allows the user to define
once the trend is recorded to either stop recording or begin to
overwright the beginning of the trend
DefaultTrend is a status to reset all trend reading back to the
unit default settings or not .
OM 1263 • MICROTECH UNIT CONTROLLER
Range
Password Level
No/Yes
2
No/Yes
2
1-3600s
2
Off/On
2
0-1440m
2
No/Yes
2
Done
2
ClrData
2
ClrCfg
2
Wrap/Stop
2
No/Yes
2
Default
There are thirty default trend points for ROC . They will only not
be recorded if manually programmed not to record .
Table 31: Default Trends Menu
Item Display
Default Setting
Name
Point 1=
INV%
Point 2=
STDOut
Point 3=
SAF%
Point 4=
EF%
Point 5=
OAD%
Point 6=
RH%
Point 7=
H/COut
Point 8=
OAT
Point 9=
ClgSt
Point 10=
HtgSt
Point 11=
Cap%In
Point 12=
INVCmd
Point 13=
CmpInLk
Point 14=
PTD
Point 15=
PTS
Point 16=
EVI%
Point 17=
EVO%
Point 18=
OAFCmd
Point 19=
OF1Spd
Point 20=
OF2Spd
Point 21=
Tc
Point 22=
TcSpt
Point 23=
DSH
Point 24=
Teg
Point 25=
SSH
Point 26=
SSHSpt
Point 27=
HDRT1
Point 28=
HDRT3
Point 29=
OilSts
Point 30=
OilMng
38
Trending
Trending
Range
Password Level
INV%
2
STDOut
2
SAF%
2
EF%
2
OAD%
2
RH%
2
H/COut
2
OAT
2
ClgSt
2
HtgSt
2
Cap%In
2
INVCmd
2
CmpInLk
2
PTD
2
PTS
2
EVI%
2
EVO%
2
OAFCmd
2
OF1Spd
2
OF2Spd
2
Tc
2
TcSpt
2
DSH
2
Teg
2
SSH
2
SSHSpt
2
HDRT1
2
HDRT3
2
OilSts
2
OilMng
2
