Alarm Log Menu
The last fifty alarm events (alarm detection and return to
normal) as well as the date and times that they were detected
are displayed on the Alarm Log menu . These alarm events are
displayed in the order that they were detected . The alarm event
that was detected most recently is displayed first. Multiple
occurrences of the same alarm may appear .
Table 39: Alarm Log Menu
Item Display Name
Log Alm Count=
ClrLog=
+Alarm 1:Alarm Type
+Alarm 2:Alarm Type
Once an alarm is cleared there will be two entries in the Alarm
Log . A (+) sign will be shown next to the entry added when the
alarm became active and a (-) sign will be shown next to the
entry added when the alarm has been cleared .
Alarm Configuration Menu
The Alarm Configuration menu is also available under the
Commission Unit menu . Refer to
Analog Input Status Menu
The Analog Input Status Menu provides diagnostic information
to qualified service personnel. The items listed in this menu will
provide current status information of the unit's analog inputs .
The value shown is the input resistance shown in 1/10th of an
ohm scale . Example: MCB-AI1 (DAT sensor) shows a value
of 181380, the actual resistance would be 18,138 ohms . This
would translate to a temperature of 53 .5 ºF .
Table 40: Analog Input Status Menu
Item Display Name
MCB-AI1=
MCB AI2=
MCB AI3=
www .DaikinApplied .com
Default Setting
—
No
—
—
page 57 .
Default Setting
—
—
—
Range
0–50
No
Yes
Range
0–99999999
0–99999999
0–99999999
63 OM 920-6 • MICROTECH UNIT CONTROLLER
M d
enu esCrIpTIons
Password Level
None
None
None
None
Password Level
2
2
2
