Figure 5: View/Set Unit – Keypad/Display Menu Structure
See page 23 – 32
View/Set Unit
►
Unit Status/Settings
►
Occupancy
►
Temperatures
►
Flow Status
►
SAF Spd Control
►
RF/EF Control
►
Cooling
►
Economizer
►
Min OA Damper
►
Heating
►
Dehumidification
►
Date/Time/Schedules
See page 23 – 24 See page 25
Unit Status/Settings Occupancy
Unit State= ___________ Occupancy= __________
Unit Status= __________ Occ Mode= Auto/Net
MWU Status= _________ OccSrc= _____________
Dehum Status= ________ UnoccSrc= ___________
Ctrl Mode= Off Tnt Ovrde Tm= 0 min
Clg Status= ___________
Htg Status= ___________
SuplHtgStatus= ________
Econo Status= _________
Clg Capacity= XXX%
Htg Capacity= XXX%
Supl Htg Cap= XXX%
Reheat Cap= XXX%
SAF Speed= XXX%
RF/EF Cap= XXX%
OAD/Econo Cap=XXX%
Rel Humidiy= XXX%
Net Emrg Ovrd= Normal
Net App Mode= Auto
www .DaikinApplied .com
See page 26 See page 27
Temperatures Flow Status
Control Temp= XXX°F Airflow= ______________
Disch Temp= XXX°F Waterflow= ___________
Return Air= XXX°F Water Pump= _________
Space Temp= XXX°F Supply Fan= __________
OA Temp= XXX°F Ret/Exh Fan= _________
EF/LC Temp= XXX°F
EW Temp= XXX°F
Mixed Air= XXX°F
ER LAT= XXX°F
ER EAT= XXX°F
Sump Temp= XXX°F
PA Temp= XXX°F
DRT1= XXX°F
DRT2= XXX°F
DRT3= XXX°F
SRT= XXX°F
DFT= XXX°F
IRT= XXX°F
ORT= XXX°F
INVCompTemp= XXX°F
10
K /d M
eypad Isplay
See page 27 and 35
SAF Speed Control
SAF Speed= XXX%
Speed Cmd= XXX%
Duct Press= X .Xin
DuctSP Spt= 1 .0in
IAQ PPM= XXXXPPM
OA Flw= XXXXXCFM
MinOAFlw Spt= 2000CFM
Bldg Press= X .XXin
BldgSP Spt= 0 .05in
OM 920-6 • MICROTECH UNIT CONTROLLER
s
enu TruCTure
See page 28 and 38
RF/EF Control
RF/EF Cap= XXX%
Speed Cmd= XXX%
Bldg Press- X .XXin
BldgSP Spt= 0 .050in
