Active Alarms Menu

All active alarms as well as the date and time that they were
detected are displayed on the Active Alarm menu . These
alarms are displayed in order of group priority: Faults first,
Problems second, and Warnings last . Within each group,
alarms are displayed in the order that they were detected .
Table 21: Active Alarm Menu
Default
Item Display Name
Setting
Active Alm Count=
ClrAlms=
+Alarm 1: Alarm Type
+Alarm 2: Alarm Type

Alarm Log Menu

The last fifty alarm events (alarm detection and return to
normal) as well as the date and times that they were detected
are displayed on the Alarm Log menu . These alarm events are
displayed in the order that they were detected . The alarm event
that was detected most recently is displayed first. Multiple
occurrences of the same alarm may appear .
Table 22: Alarm Log Menu
Default
Item Display Name
Setting
Log Alm Count=
ClrLog=
+Alarm 1: Alarm Type
+Alarm 2: Alarm Type
Once an alarm is cleared there will be two entries in the Alarm
Log . A (+) sign will be shown next to the entry added when the
alarm became active and a (-) sign will be shown next to the
entry added when the alarm has been cleared .
www .DaikinApplied .com
Password
Range
Level
— 0-10 None
No
ClrFlts
No ClrPrblms None
ClrWrngs
ClrAllAlms
— — None
— — None
Password
Range
Level
— 0-50 None
No
No None
Yes
— — None
— — None

Alarm Configuration Menu

The Alarm Configuration menu is also available under the
Commission Unit menu . Refer to

Analog Input Status Menu

The Analog Input Status Menu provides diagnostic information
to qualified service personnel. The items listed in this menu will
provide current status information of the unit's analog inputs .
The value shown is the input resistance shown in 1/10th of an
ohm scale . Example: MCB-AI1 (DAT sensor) shows a value
of 181380, the actual resistance would be 18,138 ohms . This
would translate to a temperature of 53 .5 ºF .
Table 23: Analog Input Status Menu
Item Display
Default Setting
Name
MCB AI1=
MCB AI2=
MCB AI3=
EMD AI1=
EMD AI2=
EMD AI3=
33 OM 1263 • MICROTECH UNIT CONTROLLER
Service Menus
page 30 .
Range Password Level
— 0 – 9999999
— 0 – 9999999
— 0 – 9999999
— 0 – 9999999
— 0 – 9999999
— 0 – 9999999
2
2
2
2
2
2
