Mounting

Tabletop Mounting

Attach the provided rubber feet to the bottom four corners of the enclosure.

Rack Mounting

Mount the scalers into racks with the pre-installed rack ears (see
mounted devices
rack ears on both side of the device with the screw holes in the rack so they device is level.
Use the provided screws to attach the device to the rack.
Rack Mounting
Figure 92.
Mounting
Downloading Updated Firmware
on the next page). To install the device, line up the screw holes on the
Rack Ears
1U Rack Mounting
IN1608 xi Scaling Presentation Switcher • Reference Information
UL Guidelines for rack
Rack Ears
Figure 93. 2U Rack Mounting
