  • Page 1 IN1404 Video Scaler 68-1078-01 Rev. A 12 04...
  • Page 2 Precautions Safety Instructions • English Warning This symbol is intended to alert the user of important operating and maintenance Power sources • This equipment should be operated only from the power source indicated on the product. This equipment is intended to be used with a main power system with a grounded (servicing) instructions in the literature provided with the equipment.

  • Page 3: Table Of Contents

    IN1404 application diagram ..................6 IN1404 rear panel connectors..................6 Operation ..........................8 Front panel controls....................... 8 IN1404 on-screen display menu system ................ 9 On-screen menu ......................10 Menu Commands ......................10 Video menu ........................10 Audio menu ........................12 Input menu ........................

  • Page 4: Product Overview

    CRT, LCD, DMD, ILA, D-ILA, and plasma display devices. Selectable Refresh Rate — The IN1404 output vertical refresh rate is adjustable from 60 Hz to 120 Hz. By converting PAL (50 Hz) and NTSC (60 Hz) input signals to higher, more ergonomic refresh rates, the scaler makes it possible to display a remarkably solid, flicker-free image when using CRT monitors and projectors.

  • Page 5: Compatibility

    VGA resolutions and refresh rates, ensuring optimal compatibility with a wide range of CRT, LCD, DMD, ILA, D-ILA, and plasma display devices. Dual Outputs — The IN1404 features a 5-BNC output and a 15-Pin HD (VGA) output. Since both are active simultaneously, the IN1404 can directly drive two separate display devices.

  • Page 6: Output

    Output The IN1404 features selectable output resolutions from 640 x 480 up to 1365 x 1024 to match the optimum or native resolution of virtually any display device. The unit provides a progressive scan output signal at standard resolutions and refresh rates, ensuring optimal compatibility and exceptional image quality with a wide range of CRT, LCD, DMD, ILA, D-ILA, and plasma display devices.
  • Page 7 3.5 mm mini output connector can be connected using an optional IN9107 3.5 mm stereo mini male to (2) RCA male cable. The IN1404 features a 5-BNC output and a 15-Pin HD output for easy connections to a variety of scan rate compatible displays: •...

  • Page 8: In1404 Application Diagram

    IN1404 application diagram Figure 1. — IN1404 application diagram IN1404 rear panel connectors Inputs 1-2 Inputs 3-4 Output Other S-VIDEO: RGBHV / CrYCb: VGA: RS-232: (1) 4-Pin mini DIN 5 BNC connectors for 15-Pin HD female Phoenix connector— connector universal inputs:...
  • Page 9 Figure 2. — Rear panel of the IN1404 scaler Connect the video signals to the rear of the IN1404 as shown in the table below: Signal format Inputs Signal Connection 1, 2 Composite Video BNC Composite 3, 4 Composite Y BNC...

  • Page 10: Operation

    Input Select: The large buttons labeled INPUT 1, INPUT 2, INPUT 3 and INPUT 4 in the Input Select section are used to select the desired input. After turning on the IN1404, press and release the desired Input Select button. A green LED will light underneath the button to indicate the selected input.

  • Page 11: In1404 On-Screen Display Menu System

    IN1404 on-screen display Main Menu menu system Video Audio Input Output Advanced Video Audio Input Output Advanced Brightness Bass Signal Format Resolution Factory Reset Contrast Treble Aspect Ratio Refresh Rate User Memory RGB Gain Balance Auto Switching Size Baud Rate...

  • Page 12: On-Screen Menu

    Advanced: Displays advanced options. Menu Commands Video menu The IN1404 allows you to manually adjust the brightness, contrast, color, hue, sharpness, gamma, noise filter, and comb/trap filter settings. To access the video adjustment menu via the front panel control buttons Press the desired Input Select button.
  • Page 13 Operators should adjust both settings until optimal picture quality is achieved. Range: 0 to 8 Factory default setting: 3 Operation: Press button to increase the sharpness. Press button to decrease the sharpness. IN1404 User’s Manual...

  • Page 14: Audio Menu

    Reset Video resets all video settings to factory default (for current input only). Audio menu The IN1404 allows you to manually adjust the bass, treble, and balance settings. To access the audio adjustment menu via the front panel control buttons, do the following: Press the desired Input Select button.

  • Page 15: Input Menu

    (use the blue screen if necessary). Once the IN1404 output settings and the display device settings have been properly adjusted, the IN404 input settings and video adjustments may be configured for each input signal.
  • Page 16 For Standard 1.33 input signals (sometimes referred to as full screen) Standard: Anamorphic: This setting provides vertical image squeezing to accommodate anamorphically enhanced DVDs. Wide Screen: For wide screen 1.78 input signals (letterbox) For wider screen 2.35 input signals (narrow letterbox) Wider Screen: IN1404 User’s Manual...
  • Page 17 4:3 format. The same signals are shown on the right as they would appear on 4:3 and 16:9 display devices with the scaler set to various aspect ratio settings. Example 1: Example 2 IN1404 User’s Manual...
  • Page 18 Example 3 Example 4 IN1404 User’s Manual...

  • Page 19: Output Menu

    Output Resolution: This control lets you select the appropriate resolution for your display device. The available resolutions are listed on page 22. Because the IN1404 only scales up, users must choose an output resolution that is greater than or equal to the input size. For instance, you may not select 640 x 480 output with PAL input signals since PAL has more than 480 lines of video.

  • Page 20: Advanced Menu

    This setting is useful to manually reduce the height of the output signal when an anamorphic input signal is connected. The IN1404 only scales up; therefore, the output size controls will stop at a certain point at which the input and output resolution are equal.

  • Page 21: Choosing The Optimal Resolution And Refresh Rate

    Choosing the Optimal Output Resolution and Refresh Rate Of all the settings on the IN1404, perhaps the most critical adjustment is the output resolution and output refresh rate. Every display device has an optimal or native resolution and an optimal refresh rate.

  • Page 22: Crt Displays: Selecting The Optimal Refresh Rate

    60 Hz with most LCD, DMD, LCOS, and plasma displays. Higher refresh rates are not recommended with these display technologies, because they usually do not improve the image and may actually cause compatibility problems. IN1404 User’s Manual...
  • Page 23 Plasma Display 50” / 60” (16:9) (Fujitsu / JVC / Luce / Marantz / NEC / Panasonic / RCA / Runco / Samsung / Toshiba) 1365 x 768 60 Hz NEC 50": Set sync Format to RGBHV++. IN1404 User’s Manual...

  • Page 24: Advanced Operation

    4 when set to RGB passive mode. Once you have set input 3 or input 4 for RGB passive mode, the IN1404 is functioning as a passive switcher and you will not be able to see any on-screen menus. If you wish to select a different input mode following this procedure: Select input 1 or 2 (use the front panel Input Select buttons).

  • Page 25: Default Power-Up Buttons

    Default power-up buttons An output mode, output sync format or a factory reset may be selected without the use of the IN1404 menu. This is particularly useful if the monitor does not display an image or if the image is scrambled.
  • Page 26 • Input Mode:* Four options are available: Auto Detect - The default mode at power up that allows the IN1404 to automatically detect new input modes and adjust accordingly. Lockout Changes - Prevents the IN1404 from switching back and forth between input modes, or flickering when small input mode changes occur (such as from a VCR in fast forward or reverse).

  • Page 27: Adjustment Advanced Input Settings

    In Figure 5 on the following page, the input blanking is set incorrectly (as indicated by the dashed lines). If the H-Blanking is set to less than the actual H-Blanking, the IN1404 will look for the active area before it really occurs. This results in a blank border on the left side of the active area, and cropping on the right side of the active area.

  • Page 28: Active Area Adjustment

    In Figure 6 on the following page, the active area is adjusted incorrectly, as shown by the dashed lines. If the active pixels are set to less than the actual active pixels, the IN1404 will look for the active area inside this smaller region.
  • Page 29 Input modes for horizontal scan rate = 31.5 kHz and vertical refresh rate = 60 Hz Active Pixels Active Lines Aspect Ratio Total Pixels NTSC 14.3 NTSC 13.5 NTSC 12.3 (default) Input modes for horizontal scan rate = 15.7 kHz and vertical refresh rate = 60 Hz IN1404 User’s Manual...

  • Page 30: Total Pixels Adjustment

    Alternatively, if the input pixel clock is known, the input total pixels may be calculated from the formula shown below. The input horizontal scan rate, as measured by the IN1404, can be found under System Info of the Advanced Menu section on page 18.

  • Page 31: Remote Operation

    9600 baud (factory default setting) Baud Rate Selection: The IN1404 has a factory default baud rate of 9600 bps and can communicate at baud rates from 1200 up to 57,600. Baud rates can be selected using the Advanced menu (see page 18).

  • Page 32: In1404 Serial Commands

    IN1404 serial commands* Command Description Command Description ACI3 set baud rate to 1200 BAL? return balance ACI4 set baud rate to 2400 BAS+ increase bass ACI5 set baud rate to 4800 BAS- decrease bass ACI6 set baud rate to 9600**...
  • Page 33 FMT6 set signal format to RGsB set input mode to lockout changes FMT7 set signal format to RGBGHVS passive set input mode to user defined FMT8 set signal format to RGsB passive IN1404 User’s Manual...
  • Page 34 SATxxx set color saturation to absolute value PHS- decrease phase (000-255) set phase to normal** ♦ PHS@ SAT? return color saturation PHSxxx set phase to absolute value (0-31) SCS0 set output resolution to 640 x 480** IN1404 User’s Manual...
  • Page 35 Extron reserves the right to modify, remove and/or add commands on future product revisions. The commands are not case sensitive. **Default values when the factory reset is performed ♦ Normal and available values depend on the current input or output mode. IN1404 User’s Manual...

  • Page 36: Troubleshooting

    Solution 2: Verify that the audio source is connected to the correct input and that the source volume has not been turned down or muted. Solution 3: The audio output of the IN1404 is line level audio only. It should be connected to a mixer/amplifier or to amplified “computer type” speakers.
  • Page 37 Solution 2: Reduce the Output H-Position to line up the image on the display device. Use the blue screen. Solution 3: Adjust the Monitor Position or Size Controls to fit the image on the display device. Use the blue screen. IN1404 User’s Manual...
  • Page 38 Solution 3: Change the comb or trap filter setting. Problem: The output resolution will not decrease. Solution 1: The IN1404 can only scale up. Resolutions that would result in scaling down are not available. If a lower output resolution is desired, connect a signal with a lower input Active Area.
  • Page 39 Problem: The desired input aspect ratio cannot be selected. Solution 1: The IN1404 can only scale up. Increase the output resolution until the desired aspect ratio is available. Solution 2: Manually decrease the image size by using the output menu.
  • Page 40 Solution 2: The Input Active Pixels may be set too high. Reduce the Input Active Pixels setting to match the input signal. Problem: The input V-Blanking will not increase. Solution: The Input Active Lines may be set too high. Reduce the input Active Lines setting to match the input signal. IN1404 User’s Manual...

  • Page 41: Specifications

    Gain ..........Unbalanced output: 0dB Audio input Number/signal type ....4 stereo, unbalanced Connectors ........4x2 (left and right) RCA connectors Audio output Number/signal type ....1 stereo, unbalanced Connectors ........1x2 (left and right) RCA connectors IN1404 User’s Manual...

  • Page 42: Part Numbers

    Compliances ......... CE MTBF ..........30,000 hours Warranty ........3 years parts and labor Specifications are subject to change without notice. Part Numbers These items are included with the IN1404. Included Parts Part Numbers IN1404 scaler 60-731-01 Rack mount ears for IN1403/IN1404/IN1404XT...

  • Page 43: Cables

    26-112-27 VGA 50 MHR (15.25 m) 26-112-02 VGA 75 MHR (22.9 m) 26-112-03 VGA 100’ MHR (30.5 m) 26-112-04 VGA 150’ MHR (45.7 m) 26-112-09 VGA 200’ MHR (61.7 m) 26-112-08 VGA 250’ MHR (76.2 m) 26-112-16 IN1404 User’s Manual...
  • Page 44 Mini-high resolution, plenum 22-103 22-130 Halogen free cable 22-126 Super high resolution 22-145 26-368 26-639 Super high resolution, plenum 22-146 All cable grades are available in various lengths pre-terminated with high quality BNC connectors or as bulk cable. IN1404 User’s Manual...
  • Page 45 Extron’s Warranty Extron Electronics warrants this product against defects in materials and workmanship for a period of two years from the date of purchase. In the event of malfunction during the warranty period attributable directly to faulty workmanship and/or materials, Extron Electronics will, at its option,...
  • Page 46 Kyodo Building Anaheim, CA 92805 3821 AH Amersfoort PM Industrial Building 16 Ichibancho The Netherlands Singapore 368363 Chiyoda-ku, Tokyo 102-0082 Japan 714.491.1500 +31.33.453.4040 +65.6383.4400 +81.3.3511.7655 www.extron.com Fax 714.491.1517 Fax +31.33.453.4050 Fax +65.6383.4664 Fax +81.3.3511.7656 © 2005 Extron Electronics. All rights reserved.
