X5% = Video mute on all outputs
X5^ = Volume knob group number
X5& = Gain or mute control
X5* = Gain or trim level
X5( = HDCP mode
IN1608 xi Scaling Presentation Switcher • SIS Configuration and Control
0 = all outputs are unmuted
1 = at least one output is muted
2 = at least one output is muted and sync is
disabled
= program volume (default)
1
= mic volume
3
= output volume
8
= mic 1 (mix volume only)
40100
= mic 1 (mute only)
40000
= mic 2 (mix volume only)
40101
= mic 2 (mute only)
40001
= output 1
60000
= output 2
60002
= variable output L
60004
= variable output R
60005
= digital output L
60006
= digital output R
60007
= amplified output L (stereo models) or
60008
amplified output (mono models)
= amplified output R (stereo models)
60009
to = dB value multiplied by ten, in 0.1
-1000 0
dB increments, (for example,
= default
0
= encrypts the output only when required by
0
the selected input source (default)
= always encrypts the output, regardless of
1
the HDCP status of the selected input
source
= encrypts the output only when required by
2
the selected input source. Use this setting
when DVI sink devices initially pass HDCP
encrypted content, but intermittently display
a green HDCP notification screen after a
power cycle or resuming from sleep mode.
= always encrypts the output regardless of the
3
HDCP status of the selected input source.
Use this setting when DVI sink devices
initially pass HDCP encrypted content, but
intermittently display a green HDCP
notification screen after a power cycle or
resuming from sleep mode.
= prevents HDCP encryption and
4
authentication.
= -10 dB)
-100
53
