  • Page 1 Extron IN1403-2 Video Scaler In Stock Used and in Excellent Condition Open Web Page https://www.artisantg.com/92454-2 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
  • Page 2 IN1403 Video Scaler 68-1020-01 Rev. A 12 04...
  • Page 3 Precautions Safety Instructions • English Warning This symbol is intended to alert the user of important operating and maintenance Power sources • This equipment should be operated only from the power source indicated on the product. This equipment is intended to be used with a main power system with a grounded (servicing) instructions in the literature provided with the equipment.
  • Page 4 Table of Contents Product Overview ......................2 Description........................2 Features........................... 2 Compatibility ........................3 Input..........................3 Output..........................3 Installation .......................... 4 IN1403 application diagram ..................5 Operation ..........................5 Front panel controls....................... 5 On-screen menu ......................6 On-screen menu display system ..................7 Menu Commands ......................
  • Page 5 Product Overview Description The IN1403 is a full featured video scaler that combines digital video decoding, advanced video scaling/line multiplication and a 4-input A/V switcher into a single product. Features Superb Video Scaling Technology — Employing sophisticated video de-interlacing, scaling and filtering techniques, the IN1403 offers an output signal with outstanding image detail and enhanced brightness that is entirely free of visible scan lines.
  • Page 6 System Info — A handy menu option that uses the on-screen display to show comprehensive information about the input and output signals and scaler settings. Image Size, Position and Edge Blanking Controls — Individual horizontal and vertical image adjustments make it easy to precisely fit the active video image to the display area and provide for multiple aspect ratios.
  • Page 7 Installation This section offers step-by-step instructions for installing the IN1403 Video Scaler. An application diagram is provided on page 5. CAUTION Read the instructions carefully before initiating the installation procedure. Make sure that there is no power connected to the IN1403, and that the power button is off. Place or install the IN1403 at the desired location.
  • Page 8 IN1403 application diagram Figure 1 — IN1403 application diagram Operation This section focuses on operating the IN1403 using the front panel controls and commands. All video and audio adjustments, setup functions and switching operations can be performed through the front panel or via RS-232 serial controls (see page 19) INPUT SELECT VIDEO...
  • Page 9 Freeze Frame: Allows users to freeze the video signal and display a still image. Simply press and release the button to engage the function (the green LED below the button will illuminate), then press and release it again to disengage. The FREEZE FRAME button has no effect on input 4, which is a passive input.
  • Page 10 IN1403 on-screen display menu system Main Menu Video Audio Input Output Advanced Video Audio Input Output Advanced Brightness Bass Signal Format Resolution Factory Reset Contrast Treble Aspect Ratio Refresh Rate Baud Rate Color Balance Hz Tracking Size Delimiters Reset Audio Reset Input Position System Info...
  • Page 11 Menu Commands Video Menu The IN1402 allows you to manually adjust the brightness, contrast, color, hue, sharpness, gamma, noise filter, and comb/trap filter settings. To access the video adjustment menu via the front panel control buttons Press the desired Input Select button. Press MENU.
  • Page 12 Hue (NTSC signals only) adjusts the picture’s color towards red or green. Range: 0 to 40 Factory default setting: 20 Operation: Press button to increase the green. Press button to increase the red. Sharpness uses variable filtering to affect input picture detail and definition. Increasing the sharpness setting gives the visual effect that the noise filter setting is decreasing.
  • Page 13 Comb/Trap Filter selects either the comb or trap filter (only available with composite video). The comb filter electronically provides excellent Luma/Chroma separation (separates the color from the picture signal). This greatly reduces cross-color interference and hanging dots while maintaining image bandwidth and detail. The trap filter extracts luminance from the picture.
  • Page 14 Input menu To access the input menu via the front panel control buttons Press the desired Input Select button. Press MENU, press the button (if necessary) to reach the input menu. Press ENTER. Select the setting you wish to adjust by using the buttons and pressing ENTER.
  • Page 15 Example 1: Example 2 IN1403 User’s Manual...
  • Page 16 Example 3 Example 4 Horizontal Tracking: This control adjusts horizontal sync tracking to prevent image bending (hooking) along the top of the video image. Various settings are available to compensate for different quality input signals: For poor quality video signals, such as from a VCR Very Fast: Fast: For normal quality video signals, such as from a TV...
  • Page 17 Output menu To access the output menu via the front panel control buttons, do the following: Press the desired Input Select button. Press MENU (press the button to reach the output menu, if necessary). Press ENTER. Use the buttons and the ENTER key to select the setting you wish to adjust. Press ENTER to save once you’ve optimized the setting for the current input.
  • Page 18 Factory Reset: Returns all video, audio, input, output and RS-232 settings for all inputs to factory default. Baud Rate: Allows RS-232 remote users to select the baud rate that matches their remote control device system. Delimiters: Use the on-screen menu to select the desired command code delimiters. Extron scalers can be set to recognize six sets of leading and end codes when you are using an RS-232 remote: parentheses ( ), brackets [ ], braces{ }, slashes \ /, less and greater than <...
  • Page 19 CRT displays: Selecting the optimal refresh rate CRT displays may tend to flicker at refresh rates below 70 Hz In order to achieve a solid, flicker-free image, an output refresh rate of 72 Hz or 75 Hz is recommended for most CRT displays. You should also experiment with even higher refresh rates to see if they create a better image.
  • Page 20 Display Type Suggested Optimal / Suggested Comments Native Resolution Refresh Rate CRT Displays 15” Data Monitor 800 x 600 / 1024 x 768 72 Hz / 75 Hz 17” Data Monitor 1024 x 768 72 Hz / 75 Hz 19” / 21” Data Monitor 1024 x 768 / 1280 x 1024 72 Hz –...
  • Page 21 Advanced Operation Pass-through RGB video Input 4 is for passive RGB video. No scaling or video functions are available for this input. Only switching of the RGB signal is provided from the front panel or the RS-232 control. All color and sync signals are passed through an internal distribution amplifier and then to the output connectors.
  • Page 22 Power-on settings Power-on settings let you adjust key IN1403 settings without using on-screen menus. This may be particularly helpful if the IN1403 has been accidentally set for a mode that is incompatible with the display device, preventing the viewing of the on-screen menus. To execute a Power-On setting, simply press and hold the desired front panel button (indicated in the chart below) while turning on the IN1403 power switch.
  • Page 23 Baud Rate and Protocol: • 1200-57600 baud • 9600 baud (default) • 8 data bits • 1 stop bit • no parity Baud Rate Selection: The IN1402 has a factory default baud rate of 9600 bps and can communicate at baud rates from 1200 up to 57,600.
  • Page 24 IN1403 serial commands* Command Description Command Description ACI3 set baud rate to 1200 CMDCD2 set delimiters to parentheses ( ) ACI4 set baud rate to 2400 CMDCD3 set delimiters to less and greater < > ACI5 set baud rate to 4800 CMDCD4 set delimiters to slashes \ / ACI6...
  • Page 25 Command Description Command Description BRG? return current brightness HTK1 set horizontal tracking to fast** select channel 1 HTK2 set horizontal tracking to normal select channel 2 HTK3 set horizontal tracking to slow select channel 3 HTK? return current horizontal tracking select channel 4 HUE+ increase hue...
  • Page 26 Command Description Command Description REF2 set refresh rate to 75 Hz SVxxx set vertical position to absolute value (♦-100) REF3 set refresh rate to 85 Hz return vertical size REF4 set refresh rate to 96 Hz SYNC0 set output sync to RGBHV- -** REF5 set refresh rate to 100 Hz SYNC1...
  • Page 27 Troubleshooting Problem: There is no image on the display device. • Solution 1: Make sure that the power cable is securely plugged into the unit and the A/C source. • Solution 2: Make sure the A/C source is live. • Solution 3: Verify that the power switch is turned on for the video source, the IN1403, and the monitor.
  • Page 28 Problem: The image on the display device is cropped on the right side. • Solution 1: Reduce the output H-Position to line up the image on the display device. Use the blue screen. • Solution 2: Adjust the monitor position or size controls to fit the image on the display device.
  • Page 29 Problem: The desired Input Aspect Ratio cannot be selected. • Solution 1: The IN1403 can only scale up. Increase the output resolution until the desired aspect ratio is available. • Solution 2: Manually decrease the image size by using the output menu. •...
  • Page 30 All nominal levels are at ±10%. Specifications are subject to change without notice. Part Numbers These items are included with the IN1403. Included Parts Part Numbers IN1403-2 scaler 60-730-01 Rack ears 70-391-01 Rubber feet (4) IEC power cord Extron Tweeker IN1403 User’s Manual...
  • Page 31 IN1403 User’s Manual...
  • Page 32 Extron’s Warranty Extron Electronics warrants this product against defects in materials and workmanship for a period of two years from the date of purchase. In the event of malfunction during the warranty period attributable directly to faulty workmanship and/or materials, Extron Electronics will, at its option,...
  • Page 33 Kyodo Building Anaheim, CA 92805 3821 AH Amersfoort PM Industrial Building 16 Ichibancho The Netherlands Singapore 368363 Chiyoda-ku, Tokyo 102-0082 Japan 714.491.1500 +31.33.453.4040 +65.6383.4400 +81.3.3511.7655 www.extron.com Fax 714.491.1517 Fax +31.33.453.4050 Fax +65.6383.4664 Fax +81.3.3511.7656 © 2005 Extron Electronics. All rights reserved.
