168
PostBase One Franking System
Insert cables
Power sealer (Connecting is
decribed on page 165.)
Power cable
Power cable
Connection cable
(dynamic scale – sealer)
Power supply unit
Interfaces:
Connection cable
(sealer – feeder)
Power cable
Serial interface
Interface for connection of
optional components
(e.g. feeder, sealer)
Static scale connection
PC connection
USB connection
Connection to the local network
(LAN)
FSCP plug
(termination plug)
