Contents This manual contains important information for your safety and describes how to set up and install the PostBase Fusion mail- ing system. Information that only applies to certain configura- tions and equipment variants is indicated by an addendum, for example (optional).
Page 3
_________________________13 Step 5: Turning on the PostBase Fusion __________________________15 Step 6: Installing the PostBase Fusion ____________________________15 Installing the PostBase Fusion Feeder (optional) _______________21 Step 7: Graphical symbols, safety signs and product safety labels on the PostBase Fusion ________________________________________________27 Technical Data __________________________________________________29...
Page 4
Make sure that the power connection conforms to the power requirements indi- cated on the type plates. • Make sure the outlets for connecting the PostBase Fusion are close by and easily accessible at all times. • Unplug the PostBase Fusion power plugs from the outlets in case of an emer- gency.
Page 5
• If the was previously in a cold environment (i.e. below 10 °C / 50 °F): Unpack the and wait at least two hours before setup and installation of the PostBase Fusion . The PostBase Fusion needs this time to adapt to the environmental conditions allowing any condensed moisture to escape.
Page 6
PostBase Vision Installation and commissioning This chapter describes how to set up and install the PostBase Fusion in the following versions – with hand feed tray (basic model) – with the ‘Hand-feed Sealer’ – with the ‘PostBase Fusion Feeder’. Caution! Follow the steps for setup and installation of the PostBase Fusion in precisely the given order to ensure successful installation.
Page 7
Installation and commissioning Scope of delivery PostBase Fusion franking machine Standard configuration: (1 box) 1 PostBase Fusion franking machine 2 Weighing platform 3 Ink cartridge (packaged) 4 Hand feed tray 5 Power cable 6 Ethernet cable 7 Catch tray and stop...
Page 8
PostBase Vision Optional, only if ordered separately 1 Feeder (automatic feeder with sealer) PostBase Fusion Feeder (2 boxes) 2 Power cable 3 Bottle of SEALIT (sealing fluid) 4 Replacement sponge holder with sponge 5 Ramp 6 Pendulum Drop Stacker The delivery package of the Drop Stacker is...
Page 9
Installation and commissioning Step 2: Assembling the PostBase Fusion Installation site The installation site for the PostBase Fusion must meet the following requirements: – Firm, level, low vibration and horizontal base, which offers sufficient space for the in the ordered configuration. The dimen- sions of the individual components can be found at page 29.
Page 10
Assembling the Drop Stacker Instead of the catch tray, the optional high capacity FP Drop Stacker can be placed to the right of the franking machine. For details on setting up the Drop Stacker, refer to the installation instructions supplied...
Page 11
Installation and commissioning Attaching the hand feed tray (only on the basic model) • Place the hand feed tray for manually feed- ing the items to the left of the franking machine. • Slightly lift the franking machine on the left side and push the hand feed tray towards the franking machine so that the front sides are flush.
Page 12
PostBase Vision Step 3: Assembling the hand-feed sealer (optional) The sealer is positioned to the left of the franking machine instead of the hand feed tray. The catches on the right side of the sealer and slots (on the left side of the bottom side of the franking machine) mechanically couple the two components and fasten them in position relative to each other.
Page 13
Step 4: Connecting the PostBase Fusion Caution! If the PostBase Fusion was previ- ously in a cold environment (i.e. below 10 °C / 50 °F): Wait at least two hours after unpack- ing before connecting the franking machine.
Page 14
Warning! Danger from electrical voltage if improperly connected. • Use the supplied power and connection cables or cables that have been approved by FP. Make sure that the cables are not damaged. • Only connect the PostBase Fusion to a grounded single-phase power outlet.
Page 15
‘The basics of operation’. The PostBase Fusion will guide you step-by- step through the installation procedure. Sim- ply follow the instructions on the display. • Have the R-PIN ready (received separately from the rest of the delivery).
Page 16
PostBase Vision Connectivity settings Default settings for an Ethernet connection are stored for connecting to the FP infrastruc- ture. Establishing the connection should run seamlessly with these settings. To test the connection to the FP infrastruc- ture with this default setting: •...
Page 17
Note: Do not touch the cover flap of the print system or otherwise obstruct the automatic opening. PostBase Fusion moves the print system to the change position and then opens the cover flap. The flashing green LED indicates that no cartridge has been inserted yet.
Page 18
PostBase Vision Caution! The ink contains small quantities of harmful substances that can cause irritation to the eyes, skin and respiratory tract and trigger allergic reactions. If swallowed, the ink can be harmful to your health. • Avoid eye and skin contact with the ink. •...
Page 19
• Repeat these steps to insert the second ink cartridge. • Close the printing system flap: Push the flap down at the PostBase Fusion logo until the lock snaps into place. Be patient: PostBase Fusion will now pre- pare the cartridges for use.
Page 20
PostBase Vision Load Postage In order to frank, the PostBase Fusion must have available funds. To download postage, this requires a connection to the data centre. • Follow the instructions on the display. Installation complete Home screen (example) When PostBase Fusion displays the Home screen, the franking machine installation has been successfully completed.
Page 21
Turning off the franking machine • Press the ON/OFF button for three seconds. 3 seconds The PostBase Fusion will complete any cur- rent actions, return the display to its home position, and then turn itself off. Setting up the feeder...
Page 22
PostBase Vision and are secured in position relative to each other in this way. • Lift the feeder slightly, align it to the ramp and lower it carefully. The catches on the ramp must snap into the slots on the Feeder. •...
Page 23
Be extremely careful when handling fluids. When filling the tank, make sure that no live parts become wet. However, if this does occur: Immediately disconnect the power plug. Have the PostBase Fusion checked by the Customer Support before using it again.
Page 24
PostBase Vision The sealant tank is located under the trans- parent flap. To open the flap: • Press the key. • Remove the sealant tank from the housing. • Unscrew sealant tank screw cover.
Page 25
Installation and commissioning • Fill the sealant tank with SEALIT sealing fluid. • Replace sealant tank screw cover and tighten. • Turn sealant tank upside down in a non- dangerous area (e.g. over a sink) to check if the cover is well sealed. •...
Page 26
LED status indicator (sealing function ON/OFF) on the feeder starts to light up. After the system has started up successfully, the Home screen with the additional F EEDER button appears on the display. The PostBase Fusion with feeder is ready for operation.
Page 27
PostBase Fusion Graphical symbols, safety signs and product safety labels are affixed to the PostBase Fusion . You will find the product safety labels on the type plates of the indi- vidual components. The following overview lists and explains them.
Page 28
The bar below the garbage can indicates that the product was marketed after 13 August 2005. For proper disposal and recycling of the PostBase Fusion , please contact the FP Customer Service. Interface for connection to a personal computer (PC).
Page 29
Technical Data Technical Data Dimensions * – Length 310 mm (12.2") – housing 146 mm (5.7") – hand feed tray / sealer 385 mm (15.2") – feeder 280 mm (11") – ramp 320 mm / 445 mm (12.6" / 17.5") – catch tray min / max 345 mm / 430 mm (13.6"...
Page 30
PostBase Vision Print system – Print technology Ink-jet, 1 ink cartridge – Printing area max. 185 mm × 25 mm (7.3" × 1") – Print resolution 300 dpi Weighing range Depending on machine configuration: 3 g to 7000 g (0.1 oz to 15 lb) Noise emission <...
Page 31
Material Safety Data Sheet (MSDS) for users available at sdb.francotyp.com/en. Mail piece specifications Format PostBase Fusion (franking machine with hand feed tray): (height × width) 89 mm × 127 mm up to 253 mm × 353 mm (3.5" × 5" up to 10" × 14") PostBase Fusion with feeder: 100 mm ×...
Page 32
PostBase Vision Envelope specifications for automatic sealing (PostBase Fusion Feeder) Material Envelopes must be suitable for sealing by machine. The flap must be at the envelope’s long side. Sealing area Sufficient closure can only achieved with continuous sealing area. Subject to short-term modification.
Page 33
Declaration of Conformity Declaration of Conformity...
Page 34
PostBase Vision License This is a copy of the current LICENSE file inside the CVS repository. LICENSE ISSUES ============== The OpenSSL toolkit stays under a dual license, i.e. both the conditions of the OpenSSL License and the original SSLeay license apply to the toolkit. See below for the actual license texts.
Page 35
License * This product includes cryptographic software written by Eric Young * (eay@cryptsoft.com). This product includes software written by Tim * Hudson (tjh@cryptsoft.com). Original SSLeay License ----------------------- /* Copyright (C) 1995-1998 Eric Young (eay@cryptsoft.com) * All rights reserved. * This package is an SSL implementation written * by Eric Young (eay@cryptsoft.com).
Page 36
Product Description: PostBase Fusion The PostBase Fusion is connected to the user’s local network through an Ethernet interface / Wi-Fi to share data with the FP Data Centre using both the local network and a suitable available internet connection provided by the user.
Page 37
FCC Compliance Statement FCC Compliance Statement This device complies with FCC Part 15, Subpart B, Class B. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 39
Service Service Every PostBase Fusion mailing system is thoroughly checked before leaving the factory. Should any faults occur with your PostBase Fusion mailing system in spite of our extensive quality control, please contact FP help line. Service fp-francotyp.com...
