LANCOM GS-2124
Chapter 4: Operation of Web- based Management
4.6.1

Ports

70
ACL Port Configuration
The switch ACL function support up to 128 Access Control Entries (ACEs),
using the shared 128 ACEs for ingress classification. You can create an
ACE and assign this ACE for each port with <Any> or assign this ACE for
a policy or assign this ACE for a port. There are 8 policies, each port can
select one of policy, then decides which of the following actions would
take according to the packet's IPv4, EtherType, ARP Protocol, MAC Para-
meters and VLAN parameters:
Packet Deny or Permit
Rate Limiter (Unit: pps)
Port Copy (1 - 24)
Parameter:
Port #:
Port number: 1~24
