Each data field has 20-digit long. If the counting is overflow, the counter will
be reset and restart counting. The data is updated every time interval defined
by the user. The valid range is 3 to 10 seconds. The Refresh Interval is used to
set the update frequency. Default update time is 3 seconds.
Detail Counter
Display the detailed counting number of each port's traffic. The window
can show all counter information of each port at one time.
Parameter:
Rx Packets:
The counting number of the packet received.
Rx Octets:
Total received bytes.
Rx Errors:
Number of bad packets received.
Rx Unicast Packets:
Show the counting number of the received unicast packet.
Rx Broadcast Packets:
Show the counting number of the received broadcast packet.
Rx Multicast Packets:
Show the counting number of the received multicast packet.
Rx Pause Packets:
Show the counting number of the received pause packet.
Tx Collisions:
Number of collisions transmitting frames experienced.
Tx Single Collision:
Number of frames transmitted that experienced exactly one collision.
Tx Multiple Collision:
Number of frames transmitted that experienced more than one colli-
sion.
Tx Drop Packets:
Number of frames dropped due to excessive collision, late collision, or
frame aging.
Chapter 4: Operation of Web- based Management
LANCOM GS-2124
53
