Parameter:
Frame Type:
Range: Any / Ethernet Type / ARP / IPv4
Any: It is including all frame type
Ethernet Type: It is including all Ethernet frame type
ARP: It is including all ARP protocol frame type
IPv4: It is including all IPv4 protocol frame type
ACE Configuration
The switch ACL function support up to 128 Access Control Entries (ACEs),
using the shared 128 ACEs for ingress classification. You can create an
ACE and assign this ACE for each port with <Any> or assign this ACE for
a policy or assign this ACE for a port. There are 8 policies, each port can
select one of policy, then decides which of the Permit/Deny, Rate Limita-
tion and Port Copy actions would take according to the ACL configuration
packet's IPv4, EtherType, ARP Protocol, MAC Parameters and VLAN para-
meters.
Parameter:
Ingress Port:
Range: Any / Policy 1-8 / Port 1-24
Any: Apply this ACE rule for each port ingress classification
Policy 1-8: Apply this ACE rule for specific policy
Port 1-24: Apply this ACE rule for specific port ingress classifica-
tion
IP Protocol Filter:
Range: Any / Ethernet Type / ARP / IPv4
Any: It is including all frame type
Ethernet Type: It is including all Ethernet frame type
ARP: It is including all ARP protocol frame type
IPv4: It is including all IPv4 protocol frame type
