Restricted Mode:
This function is used to restrict dynamic VLAN be created when this
port received GVRP PDU (Protocol Data Unit). There are two modes,
disable and enable, provided for the user's choice.
4.11.2

Counter

GVRP Counter
All GVRP counters are mainly divided into Received and Transmitted two
categories to let you monitor the GVRP actions. Actually, they are GARP
packets.
Chapter 4: Operation of Web- based Management
Disabled:
In this mode, the switch dynamic VLAN will be created when this
port received GVRP PDU. The default setting is Normal.
Enabled:
In this mode, the switch does not create dynamic VLAN when this
port received GVRP PDU. Except received dynamic VLAN message
of the GVRP PDU is an existed static VLAN in the switch, this port
will be added into the static VLAN members dynamically.
