Parameter:
Region Name:
0-32 characters.(A variable length text string encoded within a fixed
field of 32 octets , conforming to RFC 2271's definition of SnmpAd-
minString.)
Revision Level:
0-65.535
4.15.3

Instance View

MSTP Instance Config
Providing an MST instance table which include information (VLAN mem-
bership of a MSTI ) of all spanning instances provisioned in the particular
MST region which the bridge belongs to. Through this table, additional
MSTP configuration data can be applied and MSTP status can be retrie-
ved.
Parameter:
Instance ID:
Every spanning tree instance need to have a unique instance ID within
0~4095. Instance 0 (CIST) always exists and can not be deleted. Addi-
tional spanning instances (MSTIs) can be added or deleted. At least
one VLAN must be provisioned for an MSTI to declare the need for the
MSTI to be existent.
