LANCOM GS-2124
Chapter 4: Operation of Web- based Management
Ethertype
(Hexadecimal)
0x8847
0x8848
0x8863
0x8864
0x88BB
0x88CC
0x8E88
0x9000
0xFFFF
116
Protocol
MPLS, Multi-Protocol Label Switching (unicast).
MPLS, Multi-Protocol Label Switching (multicast).
PPPoE, PPP Over Ethernet (Discovery Stage).
PPPoE, PPP Over Ethernet (PPP Session Stage).
LWAPP, Light Weight Access Point Protocol.
LLDP, Link Layer Discovery Protocol.
EAPOL, EAP over LAN.
Loopback (Configuration Test Protocol)
reserved.
VLAN ID:
The configurable VID range:1~4094
UDP/TCP Port:
To select the UDP/TCP port classification method by Range or Specific.
UDP/TCP Port Range:
The configurable ports range: 0~65.535
You can refer to following UDP/TCP port-numbers information.
http://www.iana.org/assignments/port-numbers
UDP/TCP Port No.:
The configurable specific port value: 0~65.535
DSCP Value:
The configurable DSCP value: 0~63
Traffic Class:
Low / Normal / Medium / High
