Temperature:
Show the current temperature of module.
Vcc:
Show the working DC voltage of module.
Mon1(Bias) mA:
Show the Bias current of module.
Mon2(TX PWR):
Show the transmit power of module.
Mon3(RX PWR):
Show the receiver power of module.
4.3.10

Simple Counter

The function of Simple Counter collects any information and provides the
counting about the traffic of the port, no matter the packet is good or bad.
In the following figure, the window can show all ports' counter information at
the same time. Each data field has 20-digit long. If the counting is overflo-
wing, the counter will be reset and restart counting. The data is updated every
time interval defined by the user. The valid range is 3 to 10 seconds. The
