LANCOM GS-2124
Chapter 4: Operation of Web- based Management
142
Notification receiving" to occur. When new series of Topology Chan-
ges occur again, this counter will be reset to 0.
TOPOLOGY CHANGE COUNT(SECs):
The per spanning tree instanceTopology Change Count expresses the
time spent in unit of seconds since the beginning of the Spanning Tree
Topology Change to the end of the STP convergence. Once there is no
topology change occurring and no more topology change notification
received, the Topology Change count will be reset to 0.
Port No:
1-24
Status:
The forwarding status.Same definition as of the RSTP specification
Possible values are "FORWARDING" , "LEARNING" , "DISCARDING"
Status:
The role that a port plays in the spanning tree topology. Possible
values are "dsbl"(disable port) , "alt"(alternate port) , "bkup"(backup
port) , "ROOT"(root port) , "DSGN"(designated port) , "MSTR"(master
port). The last 3 are possible port roles for a port to transit to FOR-
WARDING state
Path Cost:
Display currently resolved port path cost value for each port in a par-
ticular spanning tree instance.
Priority:
Display port priority value for each port in a particular spanning tree
instance.
Hello:
Per port Hello Time display. It takes the following form: Current Hello
Time/Hello Time Setting
Oper. Edge:
Whether or not a port is an Edge Port in reality.
Oper. P2P:
Whether or not a port is a Point-to-Point Port in reality.
Restricted Role:
Same as mentioned in "Port Config".
