LANCOM GS-2124
Chapter 4: Operation of Web- based Management
4.6.3
Access Control List
72
Parameter:
Rate Limiter ID:
ID Range: 1~16
Rate(pps):
1 / 2 / 4 / 8 / 16 / 32 / 64 / 128 / 256 / 512 / 1K / 2K / 4K / 8K / 16K /
32K / 64K / 128K / 256K / 512K / 1024K
ACL Rate Limiter Configuration
The switch ACL function support up to 128 Access Control Entries (ACEs),
using the shared 128 ACEs for ingress classification. You can create an
ACE and assign this ACE for each port with <Any> or assign this ACE for
a policy or assign this ACE for a port. There are 8 policies, each port can
select one of policy, then decides which of the Permit/Deny, Rate Limita-
tion and Port Copy actions would take according to the ACL configuration
packet's IPv4, EtherType, ARP Protocol, MAC Parameters and VLAN para-
meters.
Parameter description:
Ingress Port:
Configurable Range: Any / Policy 1-8 / Port 1-24
Any: Apply this ACE rule for each port ingress classification
Policy 1-8: Apply this ACE rule for specific policy
Port 1-24: Apply this ACE rule for specific port ingress classification
