LANCOM GS-2124
Chapter 4: Operation of Web- based Management
138
Corresponding VLANs:
0-4095.
Multiple VLANs can belong to an MSTI. All VLANs that are not provi-
sioned through this will be automatically assigned to Instance 0(CIST).
Edit MSTI / VLAN:
See Figure. To add an MSTI and provide its VLAN members or modify
VLAN members for a specific MSTI.
Del MSTI:
To delete an MSTI.
Del All MSTI:
Deleting all provisioned MSTIs at a time.
Instance Configuration:
See Figure. To provision spanning tree performance parameters per
instance.
Port Config:
See Figure. To provision spanning tree performance parameters per
instance per port.
Instance Status:
See Figure. To show the status report of a particular spanning tree
instance.
Port Status:
See Figure. To show the status report of all ports regarding a specific
spanning tree instance.
VLAN Mapping:
VID STRING
VID STRING Example:
2.5-7.100-200.301.303.1000-1500 (Valid VID Range:1-4094)
Priority:
The priority parameter used in the CIST(Common and Internal Span-
ning Tree) connection.
0 / 4096 / 8192 / 12288 / 16384 / 20480 / 24576 / 28672 / 32768 /
36864 / 40960 / 45056 / 49152 / 53248 / 57344 / 61440
