3.4

Export/ Import Configuration File

Config File
With this function, user can back up or reload the configuration files of
Save As Start or Save As User via TFTP.
Parameter:
Export File Path:
Export Start: Export Save As Start's config file stored in the flash.
Export User-Conf: Export Save As User's config file stored in the flash.
Import File Path:
Import Start: Import Save As Start's config file stored in the flash.
Import User-Conf: Import Save As User's config file stored in the flash.
3.5

Monitoring the LANCOM Switch with LANmonitor

The current state of the device and all ports can be monitored using the LEDs
on the front panel. With LANmonitor the devices can be observed from any
workstation without being able to see the LEDs. Besides the status informa-
tion provided by the LEDs the LANmonitor provides further important infor-
mation on the ports.
3.5.1

Ethernet port status

LANmonitor displays the current status of all of the device's Ethernet ports.
This includes monitoring of the state as configured by the admin (config state)
and the actual state (link state) of the port. Each port is displayed with two
colored symbols in LANmonitor:
