ADAP-KOOL Drive AKD 102 High Power
380 - 480 V
380 - 500 V
D1 All D1 power sizes
D2 All D2 power sizes
525 - 690 V
D1 AKD 102/ : 45-90 kW
: 37-75 kW
AKD 102/ : 110-160 kW
: 90-132 kW
D2 All D2power sizes
NB!
For further information, please see the Instruction Sheet,

3.4.5 Installation of Mains Shield for Frequency Converters

This section is for the installation of a mains shield for the frequency converter series with D1, D2 and E1 frames. It is not possible to install in the IP00/
Chassis versions as these have included as standard a metal cover. These shields satisfy VBG-4 requirements.
Ordering numbers:
Frames D1 and D2 : 176F0799
NB!
For further information, please see the Instruction Sheet,
Fuses Disconnect Fuses
176F8442 176F8450
176F8443 176F8441
Fuses Disconnect Fuses
175L8829 175L8828
175L8442 175L8445
175L8827 175L8826
175R5795
175R5923
MG.11.O1.02 - ADAP-KOOL ® is a registered Danfoss trademark
3 Mechanical Installation
RFI RFI Fuses
176F8444 176F8448
176F8445 176F8449
RFI RFI Fuses
175L8777 NA
175L8777 NA
175L8825 NA
RFI Disconnect
Fuses
176F8446
176F8447
RFI Disconnect
Fuses
3
NA
NA
NA
31
