ADAP-KOOL Drive AKD 102 High Power
Mains Supply 3 x 380 - 480 VAC
Typical Shaft output at
400 V [kW]
Typical Shaft output at
460 V [HP]
Enclosure IP21
Enclosure IP54
Enclosure IP00
Output current
Continuous
(at 400 V) [A]
Intermittent (60 sec
overload)
(at 400 V) [A]
Continuous
(at 460/ 480 V) [A]
Intermittent (60 sec
overload)
(at 460/ 480 V) [A]
Continuous KVA
(at 400 V) [KVA]
Continuous KVA
(at 460 V) [KVA]
Max. input current
Continuous
(at 400 V ) [A]
Continuous
(at 460/ 480 V) [A]
Max. cable size, mains
motor, brake and load
share [mm
Max. external pre-
1
fuses [A]
Estimated power loss
at rated max. load [W]
4)
, 400 V
Estimated power loss
at rated max. load [W]
4)
, 460 V
Weight,
enclosure IP21, IP 54
[kg]
Weight,
enclosure IP00 [kg]
Efficiency 4)
Output frequency
Heatsink overtemp.
trip
Power card ambient
trip
P110
110
150
D1
D1
D3
212
233
190
209
147
151
204
183
2 x 70
(2 x 2/0)
2 2)
(AWG )]
300
3234
2947
96
82
85 °C
MG.11.O1.02 - ADAP-KOOL
P132 P160
132 160
200 250
D1 D2
D1 D2
D3 D4
260 315
286 347
240 302
264 332
180 218
191 241
251 304
231 291
2 x 70 2 x 150
(2 x 2/0) (2 x 300 mcm)
350 400
3782 4213
3665 4063
104 125
91 112
0.98
0 - 800 Hz
90 °C 105 °C
60 °C
