ADAP-KOOL Drive AKD 102 High Power
1-39 Motor Poles
Range:
4. N/A* [2 - 100 N/A]
4-12 Motor Speed Low Limit [Hz]
Range:
0 Hz* [0 - par. 4-14 Hz]
4-14 Motor Speed High Limit [Hz]
Range:
50/60.0 [par. 4-12 - par. 4-19 Hz]
Hz*
NB!
Max. output frequency cannot exceed 10% of the inverter switching frequency (par.14-01
3-02 Minimum Reference
Range:
0.000 Ref- [-999999.999 - par. 3-03 Referen-
erenceFeed- ceFeedbackUnit]
backUnit*
Function:
Enter the number of motor poles.
Poles ~n @ 50 Hz
n
2 2700 - 2880
4 1350 - 1450
6 700 - 960
The table shows the number of poles for normal speed ranges of various motor types. Define motors
designed for other frequencies separately. The motor pole value is always an even number, because
it refers to the total number of poles, not pairs of poles. The frequency converter creates the initial
setting of par.1-39 Motor Poles
Motor Nominal Speed Motor Nominal Speed
1-25
This parameter cannot be adjusted while the motor is running.
Function:
Enter the minimum limit for motor speed. The Motor Speed Low Limit can be set to correspond to
the minimum output frequency of the motor shaft. The Speed Low Limit must not exceed the setting
Motor Speed High Limit [Hz]
in par.4-14
Function:
Enter the maximum limit for motor speed. The Motor Speed High Limit can be set to correspond to
the manufacturer's recommended maximum of the motor shaft. The Motor Speed High Limit must
Motor Speed Low Limit [Hz]
exceed the in par.4-12
Motor Speed Low Limit [Hz]
par.4-12
Menu and depending on default settings dependant on global location.
Function:
Enter the Minimum Reference. The Minimum Reference is the lowest value obtainable by summing
all references. The Minimum Reference value and unit matches the configuration choice made in
par.1-00 Configuration Mode and par. 20-12
NB!
This parameter is used in open loop only.
MG.11.O1.02 - ADAP-KOOL ® is a registered Danfoss trademark
6 How to Programme the Frequency Converter
~n @60 Hz
n
3250 - 3460
1625 - 1730
840 - 1153
based on par.1-23 Motor Frequency Motor Frequency
.
.
Motor Speed Low Limit [RPM]
. Only par.4-11
will be displayed depending on other parameters in the Main
Switching Frequency
Reference/Feedback Unit
and par.
6
or
).
, respectively.
