6 How to Programme the Frequency Converter
[101] Reference Min-Max
[102] Feedback +-200%
[103] Motor cur. 0-Imax
[104] Torque 0-Tlim
[105] Torque 0-Tnom
[106] Power 0-Pnom
[107] * Speed 0-HighLim
[113] Ext. Closed Loop 1
[114] Ext. Closed Loop 2
[115] Ext. Closed Loop 3
[130] Out frq 0-100 4-20mA
6
[131] Reference 4-20mA
[132] Feedback 4-20mA
[133] Motor cur. 4-20mA
[134] Torq.0-lim 4-20 mA
[135] Torq.0-nom 4-20mA
[136] Power 4-20mA
[137] Speed 4-20mA
[139] Bus ctrl.
[140] Bus ctrl. 4-20 mA
[141] Bus ctrl t.o.
[142] Bus ctrl t.o. 4-20mA
[143] Ext. CL 1 4-20mA
[144] Ext. CL 2 4-20mA
[145] Ext. CL 3 4-20mA
NB!
Values for setting the Minimum Reference is found in open loop par.3-02
Feedb.
- values for maximum reference for open loop is found in par.3-03
Feedb.
.
6-51 Terminal 42 Output Min Scale
Range:
0.00 %* [0.00 - 200.00 %]
86
: Minimum reference - Maximum reference, (0-20 mA)
: -200% to +200% of par. 20-14 Maximum Reference/Feedb.
: 0 - Inverter Max. Current (par. 16-37
Torque Limit Motor Mode
: 0 - Torque limit (par. 4-16
: 0 - Motor rated torque, (0-20 mA)
: 0 - Motor rated power, (0-20 mA)
Motor Speed High Limit [RPM]
: 0 - Speed High Limit (par.4-13
[Hz]
), (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100 Hz
: Minimum Reference - Maximum Reference
: -200% to +200% of par. 20-14 Maximum Reference/Feedb.
: 0 - Inverter Max. Current (par. 16-37
Torque Limit Motor Mode
: 0 - Torque limit (par. 4-16
: 0 - Motor rated torque
: 0 - Motor rated power
: 0 - Speed High Limit (4-13 and 4-14)
: 0 - 100%, (0-20 mA)
: 0 - 100%
: 0 - 100%, (0-20 mA)
: 0 - 100%
: 0 - 100%
: 0 - 100%
: 0 - 100%
Minimum Reference
Maximum Reference
Function:
Scale for the minimum output (0 or 4 mA) of the analogue signal at terminal 42.
Set the value to be the percentage of the full range of the variable selected in par.6-50
42 Output .
MG.11.O1.02 - ADAP-KOOL ® is a registered Danfoss trademark
®
ADAP-KOOL Drive AKD 102 High Power
, (0-20 mA)
Inv. Max. Current
), (0-20 mA)
), (0-20 mA)
Motor Speed High Limit
and par.4-14
Inv. Max. Current
)
)
and for closed loop par. 20-13
and for closed loop par. 20-14
Minimum Reference/
Maximum Reference/
Terminal
