4 Electrical Installation
Term. no. 96
U
U1
W2
U1
1)
Protected Earth Connection
4
Illustration 4.1: Compact IP 21 (NEMA 1) and IP 54 (NEMA 12), frame size D1
Illustration 4.2: Compact IP 21 (NEMA 1) and IP 54 (NEMA 12) with disconnect, fuse and RFI filter, frame size D2
34
97 98 99
V W 1) Motor voltage 0-100% of mains voltage.
PE
3 wires out of motor
V1 W1 Delta-connected
PE 1)
U2 V2 6 wires out of motor
V1 W1 Star-connected U2, V2, W2
PE 1)
U2, V2 and W2 to be interconnected separately.
MG.11.O1.02 - ADAP-KOOL
ADAP-KOOL
NB!
In motors without phase insulation paper or other in-
sulation reinforcement suitable for operation with volt-
age supply (such as a frequency converter), fit a Sine-
wave filter on the output of the frequency converter.
® is a registered Danfoss trademark
®
Drive AKD 102 High Power
