ADAP-KOOL Drive AKD 102 High Power
NB!
Danfoss recommends using 24 VDC as thermistor supply voltage.
1-93 Thermistor Source
Option:
[0] * None
[1] Analog input 53
[2] Analog input 54
[3] Digital input 18
[4] Digital input 19
[5] Digital input 32
[6] Digital input 33
NB!
This parameter cannot be adjusted while the motor is running.
NB!
Digital input should be set to [0]
3-10 Preset Reference
Array [8]
Range:
0.00 %* [-100.00 - 100.00 %]
Function:
Select the input to which the thermistor (PTC sensor) should be connected. An analog input option
[1] or [2] cannot be selected if the analog input is already in use as a reference source (selected in
Reference 1 Source
par.3-15 , par.3-16
When using MCB112, choice [0]
PNP - Active at 24V in parameter 5-00.
Function:
Enter up to eight different preset references (0-7) in this parameter, using array programming. The
preset reference is stated as a percentage of the value Ref
Maximum Reference/Feedb.
closed loop see par. 20-14
set ref. bit 0 / 1 / 2 [16], [17] or [18] for the corresponding digital inputs in parameter group 5-1*
Digital Inputs.
MG.11.O1.02 - ADAP-KOOL ® is a registered Danfoss trademark
6 How to Programme the Frequency Converter
Reference 2 Source
or par. 3-17
None must always be selected.
(par.3-03
MAX
). When using preset references, select Pre-
6
Reference 3 Source
).
Maximum Reference , for
