6 How to Programme the Frequency Converter
Illustration 6.2: Step 1: Turn on the frequency converter
(yellow LED lights)
6
Illustration 6.3: Step 2: Press the [Quick Menus] button
(Quick Menus choices appear).
Illustration 6.4: Step 3: Use the up/down navigation keys to
scroll down to Function Setups. Press [OK].
Illustration 6.5: Step 4: Function Setups choices appear.
Choose 03-1 General Settings
The Function Setup parameters are grouped in the following way:
Q3-10 Adv. Motor Settings
1-90 Motor Thermal Protection 6-50 Terminal 42 Output
1-93 Thermistor Source
1-29 Automatic Motor Adaption 6-52 Terminal 42 Output max. scale 0-72 Time format
14-01 Switching Frequency
76
. Press [OK].
Q3-1 General Settings
Q3-11 Analog Output
6-51 Terminal 42 Output min. scale 0-71 Date format
MG.11.O1.02 - ADAP-KOOL
ADAP-KOOL
Illustration 6.6: Step 5: Use the up/down navigation keys to
scroll down to i.e. 03-11
Illustration 6.7: Step 6: Choose parameter 6-50
Output
. Press [OK].
Illustration 6.8: Step 7: Use the up/down navigation keys to
select between the different choices. Press [OK].
Q3-12 Clock Settings Q3-13 Display Settings
0-70 Set date and time 0-20 Display Line 1.1 Small
0-21 Display Line 1.2 Small
0-22 Display Line 1.3 Small
0-74 DST/Summertime 0-23 Display Line 2 large
0-76 DST/Summertime start 0-24 Display Line 3 large
0-77 DST/Summertime end 0-37 Display Text 1
0-38 Display Text 2
0-39 Display Text 3
® is a registered Danfoss trademark
®
Drive AKD 102 High Power
Analog Outputs . Press [OK].
Terminal 42
