ADAP-KOOL Drive AKD 102 High Power
0-01 Language
Option:
[0] * English
[1] German
[2] French
[4] Spanish
[5] Italian
[7] Dutch
1-03 Torque Characteristics
Option:
[0] * Compressor CT
[1] Condenser VT
[2] Compressor AEO CT
[3] Single fan/ pump AEO
1-20 Motor Power [kW]
Range:
4.00 kW* [0.09 - 3000.00 kW]
1-21 Motor Power [HP]
Range:
4.00 hp* [0.09 - 3000.00 hp]
Function:
Defines the language to be used in the display.
The frequency converter can be delivered with 4 different language packages. English and German
are included in all packages. English cannot be erased or manipulated.
Part of Language packages 1 - 4
Part of Language packages 1 - 4
Part of Language package 1
Part of Language package 1
Part of Language package 1
Part of Language package 1
Function:
For speed control of screw and scroll compressors. Provides a voltage which is optimized for a
constant torque load characteristic of the motor in the entire range down to 15 Hz.
For speed control of centrifugal pumps and fans. Also to be used when controlling more than one
motor from the same frequency converter (e.g. multiple condenser fans or cooling tower fans).
Provides a voltage which is optimized for a squared torque load characteristic of the motor.
Auto Energy Optimization Compressor
scroll compressors. Provides a voltage which is optimized for a constant torque load characteristic
of the motor in the entire range down to 15Hz but in addition the AEO feature will adapt the voltage
exactly to the current load situation, thereby reducing energy consumption and audible noise from
the motor. To obtain optimal performance, the motor power factor cos phi must be set correctly.
This value is set in par. 14-43, Motor cos phi. The parameter has a default value which is automat-
ically adjusted when the motor data is programmed. These settings will typically ensure optimum
motor voltage but if the motor power factor cos phi requires tuning, an AMA function can be carried
out using par. 1-29, Automatic Motor Adaptation (AMA). It is very rarely necessary to adjust the
motor power factor parameter manually.
Auto Energy Optimization VT
. For optimum energy efficient speed control of centrifugal pumps and
fans. Provides a voltage which is optimized for a squared torque load characteristic of the motor
but in addition the AEO feature will adapt the voltage exactly to the current load situation, thereby
reducing energy consumption and audible noise from the motor. To obtain optimal performance,
the motor power factor cos phi must be set correctly. This value is set in par. 14-43, Motor cos phi.
The parameter has a default value and is automatically adjusted when the motor data is program-
med. These settings will typically ensure optimum motor voltage but if the motor power factor cos
phi requires tuning, an AMA function can be carried out using par. 1-29, Automatic Motor Adaptation
(AMA). It is very rarely necessary to adjust the motor power factor parameter manually.
Function:
Enter the nominal motor power in kW according to the motor nameplate data. The default value
corresponds to the nominal rated output of the unit.
This parameter cannot be adjusted while the motor is running. Depending on the choices made in
Regional Settings
par. 0-03 , either par.1-20
made invisible.
Function:
Enter the nominal motor power in HP according to the motor nameplate data. The default value
corresponds to the nominal rated output of the unit.
This parameter cannot be adjusted while the motor is running.
Depending on the choices made in par. 0-03
Motor Power [HP]
or par.1-21
MG.11.O1.02 - ADAP-KOOL ® is a registered Danfoss trademark
6 How to Programme the Frequency Converter
. For optimum energy efficient speed control of screw and
Motor Power [kW]
or par.1-21
Regional Settings
, either par.1-20
is made invisible.
6
Motor Power [HP]
is
Motor Power [kW]
