ADAP-KOOL
Drive AKD 102 High Power
1-29 Automatic Motor Adaptation (AMA)
Option:
[0] *
Off
[1]
Enable complete AMA
[2]
Enable reduced AMA
Activate the AMA function by pressing [Hand on] after selecting [1] or [2]. See also the item
normal sequence, the display will read: "Press [OK] to finish AMA". After pressing the [OK] key the frequency converter is ready for operation.
Note:
For the best adaptation of the frequency converter, run AMA on a cold motor
AMA cannot be performed while the motor is running
NB!
It is important to set motor par. 1-2* Motor Data correctly, since these form part of the AMA algorithm. An AMA must be performed
to achieve optimum dynamic motor performance. It may take up to 10 min., depending on motor power rating.
NB!
Avoid generating external torque during AMA.
NB!
If one of the settings in par. 1-2* Motor Data is changed, par. 1-30
parameters, will return to default setting.
This parameter cannot be adjusted while the motor is running.
NB!
Full AMA should be run without filter only while reduced AMA should be run with filter.
Application Examples > Automatic Motor Adaptation
See section:
6.1.3 Function Setups
The Function set-up provides quick and easy access to all parameters required for the majority of ADAP-KOOL applications including most VAV and CAV
supply and return fans, cooling tower fans, Primary, Secondary and Condenser Water Pumps and other pump, fan and compressor applications.
How to access Function Set-up - example
How to change the output on "Analog output 42"
Function:
The AMA function optimizes dynamic motor performance by automatically optimizing the advanced
Stator Resistance (Rs)
motor parameters par. 1-30
motor is stationary.
No function
performs AMA of the stator resistance R
the rotor leakage reactance X
2
performs a reduced AMA of the stator resistance R
filter is used between the frequency converter and the motor.
in the Design Guide.
MG.11.O1.02 - ADAP-KOOL
®
is a registered Danfoss trademark
6 How to Programme the Frequency Converter
Main Reactance (Xh)
to par. 1-35
, the rotor resistance R
, the stator leakage reactance X
S
r
and the main reactance X
.
h
in the system only. Select this option if an LC
s
Automatic Motor Adaptation
Stator Resistance (Rs)
Motor Poles
to par.1-39
) while the
,
1
in the Design Guide. After a
6
, the advanced motor
75
