6 How to Programme the Frequency Converter
[21] Speed up
[22] Speed down
[23] Set-up select bit 0
[24] Set-up select bit 1
[34] Ramp bit 0
[36] Mains failure inverse
[39] Day/ Night Control
[52] Run Permissive
6
[53] Hand start
[54] Auto start
[55] DigiPot Increase
[56] DigiPot Decrease
[57] DigiPot Clear
[62] Reset Counter A
[63] Counter B (up)
[65] Reset Counter B
[66] Sleep Mode
[78] Reset Preventive Maintenance Word Resets all data in par. 16-96
[120] Lead Pump Start
[130] Comp. 1 Interlock
[131] Comp. 2 Interlock
[132] Comp. 3 Interlock
[139] Comp. 1 Inv. Interlock
[140] Comp. 2 Inv. Interlock
[141] Comp. 3 Inv. Interlock
74
For digital control of the up/down speed is desired (motor potentiometer). Activate this function by
selecting either Freeze reference or Freeze output. When Speed up is activated for less than 400
msec. the resulting reference will be increased by 0.1 %. If Speed up is activated for more than 400
msec. the resulting reference will ramp according to Ramp 1 in par.3-41
Same as Speed up [21].
Selects one of the four set-ups. Set par. 0-10 to Multi Set-up.
Same as Set-up select bit 0 [23].
(Default Digital input 32)
Select which ramp to use. Logic "0" will select ramp 1 while logic "1" will select ramp 2.
Select to activate function selected in par. 14-10
"0" situation.
The input terminal, for which the Run permissive has been programmed must be logic "1" before a
start command can be accepted. Run permissive has a logic 'AND' function related to the terminal
START
which is programmed for [8],
start running the motor, both conditions must be fulfilled. If Run Permissive is programmed on
multiple terminals, Run permissive needs only be logic '1' on one of the terminals for the function
to be carried out. The digital output signal for Run Request (
[20]) programmed in par. 5-3*, or par. 5-4*, will not be affected by Run Permissive.
A signal applied will put the frequency converter into Hand mode as if button
has been pressed and a normal stop command will be overridden. If disconnecting the signal, the
motor will stop. To make any other start commands valid, another digital input must be assign to
Auto Start
and a signal applied to this. The
Off
The button on the LCP will override
On Hand Start Auto Start
button to make and
Auto Start
, the motor will stop regardless of any normal Start command applied. If signal applied
to both Hand Start and Auto Start , the function will be
LCP the motor will stop regardless of signals on
A signal applied will put the frequency converter into Auto mode as if the LCP button
been pressed. See also Hand Start [53]
Uses the input as an INCREASE signal to the Digital Potentiometer function described in parameter
group 3-9*
Uses the input as a DECREASE signal to the Digital Potentiometer function described in parameter
group 3-9*
Uses the input to CLEAR the Digital Potentiometer reference described in parameter group 3-9*
Input for reset of counter A.
(Terminal 29 and 33 only) Input for increment counting in the SLC counter.
Input for reset of counter B.
Forces frequency converter into Sleep Mode (see par. 22-4*).
Maintenance Word
Starts/ stops the lead pump (controlled by AKD 102).
The input signal must be low before the AKD 102 is able to start compressor 1.
The input signal must be low before the AKD 102 is able to start compressor 2.
The input signal must be low before the AKD 102 is able to start compressor 3.
The input signal must be high before the AKD 102 is able to start compressor 1.
The input signal must be high before the AKD 102 is able to start compressor 2.
The input signal must be high before the AKD 102 is able to start compressor 3.
MG.11.O1.02 - ADAP-KOOL ® is a registered Danfoss trademark
®
ADAP-KOOL Drive AKD 102 High Power
Ramp 1 Ramp Up Time
Mains Failure . Mains failure is active in the Logic
Jog Freeze Output
[14] or [20], which means that in order to
Start [8], Jog
Hand On Auto On
and buttons on the LCP has no impact.
Hand Start Auto Start
and . Press either the
active again. If no signal on neither
Auto Start . If pressing the
Hand Start and Auto Start
to 0.
.
[14] or Freeze output
Hand On on the LCP
Hand On Auto
or
Hand Start
nor
Off button on the
.
Auto On has
