6 How to Programme the Frequency Converter
[1835] Analog Out X42/11 [V]
[2117] Ext. 1 Reference [Unit]
[2118] Ext. 1 Feedback [Unit]
[2119] Ext. 1 Output [%]
[2137] Ext. 2 Reference [Unit]
[2138] Ext. 2 Feedback [Unit]
[2139] Ext. 2 Output [%]
[2157] Ext. 3 Reference [Unit]
[2158] Ext. 3 Feedback [Unit]
[2159] Ext. 3 Output [%]
[2230] No-Flow Power
[2580] Pack Status
[2581] Compressor Status
0-21 Display Line 1.2 Small
6
The options are the same as those listed for par 0-20
Option:
[1614] * Motor Current [A]
0-22 Display Line 1.3 Small
The options are the same as those listed for par 0-20
Option:
[1610] * Power [kW]
0-23 Display Line 2 Large
The options are the same as those listed for par 0-20
Option:
[1613] * Frequency [Hz]
0-24 Display Line 3 Large
The options are the same as those listed for par 0-20
Option:
[1502] * Counter [kWh]
0-37 Display Text 1
Range:
0 N/A* [0 - 0 N/A]
80
Shows the value of the signal applied to terminal X42/11 on the Analog I/O card.
The value of the reference for extended Closed Loop Controller 1
The value of the feedback signal for extended Closed Loop Controller 1
The value of the output from extended Closed Loop Controller 1
The value of the reference for extended Closed Loop Controller 2
The value of the feedback signal for extended Closed Loop Controller 2
The value of the output from extended Closed Loop Controller 2
The value of the reference for extended Closed Loop Controller 3
The value of the feedback signal for extended Closed Loop Controller 3
The value of the output from extended Closed Loop Controller 3
The calculated No Flow Power for the actual operating speed
Status for the operation of the Pack Controller
Status for the operation of each individual compressor controlled by the Pack Controller
Display Line 1.1 Small
Function:
Select a variable for display in line 1, middle position.
Display Line 1.1 Small
Function:
Select a variable for display in line 1, right position.
Display Line 1.1 Small
Function:
Select a variable for display in line 2.
Display Line 1.1 Small
Function:
Select a variable for display in line 3.
Function:
In this parameter it is possible to write an individual text string for display in the LCP or to be read
via serial communication. If to be displayed permanently select Display Text 1 in par. 0-20
Line 1.1 Small , par. 0-21 Display Line 1.2 Small
Line 2 Large Display Line 3 Large
or par. 0-24
◀ ▶
character. Use the and buttons to move the cursor. When a character is highlighted by the
▲
cursor, it can be changed. Use the
can be inserted by placing the cursor between two characters and pressing
MG.11.O1.02 - ADAP-KOOL ® is a registered Danfoss trademark
®
ADAP-KOOL Drive AKD 102 High Power
, par. 0-22 Display Line 1.3 Small
▲ ▼
. Use the or buttons on the LCP to change a
▼
or buttons on the LCP to change a character. A character
Display
, par. 0-23 Display
▲ ▼
or .
