Segger J-Link User Manual page 280

280
PIN SIGNAL
22 Trace signal 9
23 Trace signal 20
24 Trace signal 8
25 Trace signal 19
26 Trace signal 7
27 Trace signal 18
28 Trace signal 6
29 Trace signal 17
30 Trace signal 5
31 Trace signal 16
32 Trace signal 4
33 Trace signal 15
34 Trace signal 3
35 Trace signal 14
36 Trace signal 2
37 Trace signal 13
38 Trace signal 1
Table 10.6: JTAG+Trace connector pinout
J-Link / J-Trace (UM08001)
CHAPTER 10
Trace signals. For more information, please refer to
Assignment of trace information pins between ETM archi-
tecture versions on page 281.
© 2004-2013 SEGGER Microcontroller GmbH & Co. KG
Target interfaces and adapters
Description
