Power supply
Target interface voltage (V
Target supply voltage
Target supply current
LOW level input voltage (V
HIGH level input voltage (V
Data input rise time (T
Data input fall time (T
Data output rise time (T
Data output fall time (T
Clock rise time (T
Clock fall time (T
Table 1.4: J-Link Lite Cortex-M specifications
1.3.7

J-Trace ARM

J-Trace is a JTAG emulator designed for ARM cores which
includes trace (ETM) support. It connects via USB to a PC run-
ning Microsoft Windows 2000 or later. For a complete list of all
operating systems which are supported, please refer to Sup-
ported OS on page 19. J-Trace has a built-in 20-pin JTAG con-
nector and a built in 38-pin JTAG+Trace connector, which are
compatible to the standard 20-pin connector and 38-pin con-
nector defined by ARM.
1.3.7.1 Additional features
• Supports tracing on ARM7/9 targets
• JTAG speed up to 12 MHz
• Download speed up to 420 Kbytes/second *
• DCC speed up to 600 Kbytes/second *
* = Measured with J-Trace, ARM7 @ 50 MHz, 12MHz JTAG
speed.
1.3.7.2 Specifications for J-Trace
Supported OS
Electromagnetic Compatibility (EMC)
Operating Temperature
Storage Temperature
Relative Humidity (non-condensing)
Size (without cables)
Weight (without cables)
USB Interface
Target Interface
Table 1.5: J-Trace specifications
J-Link / J-Trace (UM08001)
)
IF
)
IL
)
IH
JTAG/SWD Interface, Timing
)
rdi
)
fdi
)
rdo
)
fdo
)
rc
)
fc
Mechanical
USB powered
Max. 50mA + Target Supply current.
3.3V
4.5V ... 5V
Max. 300mA
Max. 40% of V
IF
Min. 60% of V
IF
Max. 20ns
Max. 20ns
Max. 10ns
Max. 10ns
Max. 10ns
Max. 10ns
General
For a complete list of all operating sys-
tems which are supported, please refer
to Supported OS on page 23.
EN 55022, EN 55024
+5°C ... +40°C
-20°C ... +65 °C
<90% rH
123mm x 68mm x 30mm
120g
USB 2.0, full speed
JTAG 20-pin (14-pin adapter available)
JTAG+Trace: Mictor, 38-pin
© 2004-2013 SEGGER Microcontroller GmbH & Co. KG
