Removing and Replacing LANserver EX3 Drives

c
c
To set virtual memory size:
1. Right-click the My Computer icon on the desktop, and select Properties.
The System Properties dialog box opens.
2. Click the Advanced tab. The advanced settings appear.
3. Click the Performance Options button. The Performance Options dialog
box opens.
4. Click the Change button. The Virtual Memory dialog box opens.
5. Select C: in the Drive [Volume Label] list.
Make sure you select a drive or partition with sufficient free space for the
swap file.
6. Double-click the text box next to Initial Size (MB) and type
7. Double-click the text box next to Maximum Size (MB) and type
8. Click Set.
9. Click OK to close the Virtual Memory dialog box.
10. Click OK to close the Performance Options dialog box
11. Close the System Properties dialog box.
12. Click the Start button, and select Shut Down. The Shut Down Windows
dialog box opens.
13. Select Restart from the menu, and click OK. The new virtual memory size
takes effect after the restart is complete.
You might need to remove and replace a LANserver EX3 drive if you have a
bad drive in your Data Drive Set. You should only remove drives from the
LANserver EX3 when specifically asked by Avid Customer Support.
Removing a drive from the LANserver EX3 while it is running might
cause a loss of data. Make sure you use the following procedure to remove
drives from the LANserver EX3
You should never replace a LANserver drive with a MEDIArray ZX or
MEDIArray ZX3 drive.
Removing and Replacing LANserver EX3 Drives
.
1536
.
3072
73
