Appendix C Upgrading from MediaShare F/C
Connecting MediaShare F/C Clients to a LANshare
Workgroup
Gigabit Ethernet
LANserver EX
100
When you are copying data from a MediaShare F/C workgroup to a LANshare
workgroup, you need to have one or more clients connected directly to both
workgroups. This requires an Ethernet connection to LANshare and a Fibre
Channel connection to the MediaShare F/C hub (see
LANshare to MediaShare F/C Connection
100BASE-T Ethernet
To connect a MediaShare F/C client to a LANshare workgroup:
1. Leave the MediaShare F/C cable connected to the MediaShare F/C hub
(see Figure ).
2. Connect the client to a LANshare workgroup, and install and configure
the Macintosh Ethernet client software as described in the Avid Unity
MediaNetwork Macintosh Ethernet Client Setup Guide.
Macintosh client
Macintosh client
Ethernet client
Ethernet client
...
Fibre Channel
Figure ).
MediaShare
storage
