SDI7 module factory default settings

TG8000 Multiformat Test Signal Generator User Manual
SDI7 Dual Channel SD/HD/3G SDI Video Generator module
The following table shows the factory default settings for the SDI7 module.
These settings are recalled when you select Factory Default from the PRESET :
RECALL menu item in the mainframe main menu.
Table 3-69: SDI7 module factory default settings
Menu item name
TEST SIGNAL
FORMAT
SAMPLE STRUCTURE/DEPTH
OUTPUT MODE
MOVING PICTURE
H Step
V Step
Period
Random
OVERLAY : LOGO
Status
Source
X Position
Y Position
OVERLAY : ID TEXT
Status
Source
X Position
Y Position
Font Size
Settings
100% Color Bars
1080 59.94i
YCbCr 4:2:2 10b
HD (1920 × 1080)
0 Sample(s)
0 Line(s)
1 Frame(s)
Disable
Disable
NOTE.
The default logo is the "first" file in the
SDI7/LOGO directory, as sorted by the date of
the logo file (oldest first). If the factory-provided
logo files are installed, the default logo is
"Tektronix_logo_500x125.bmp."
However, if the user has removed the
factory-provided logo files and added their own
custom files, then the default logo will be the oldest
file installed in the SDI7/LOGO directory.
–5 % APW
–5 % APH
Disable
User-entered string
5.0 % APW
5.0 % APH
8.0 % APH
3–337
