GPS7 module main menu

TG8000 Multiformat Test Signal Generator User Manual
Use the GPS7 module main menu to perform the following tasks:
View the status of the module and signal
View diagnostics results for the module
Select the LTC output or GPI input and output
Select the GPS signal type (GPS only, GLONASS only or GPS & GLONASS)
Set the antenna voltage, time-of-day, and other time related parameters
Generate a Black 1, Black 2, or Black 3 signal
Set the timing reference source (Internal, Genlock, or GPS signal)
Set the Genlock Timing
Set the Time Of Day source (Internal, VITC input, or GPS signal)
NOTE. Earlier GPS7 modules do not have the REF IN input connector (shared
with the BLACK 1 output connector). Modules without REF IN do not support
Genlock.
Menus illustrated in this manual represent the newest features. GPS7 modules
without the REF IN input have similar menu structures but not identical menu
content.
GPS7 GPS Synchronization and Timecode module
3–113
