BG7 Black Generator module

BG7 module product description

TG8000 Multiformat Test Signal Generator User Manual
This section describes the module-specific functions of the BG7 Black Generator
module. Refer to the following locations for additional information about this
module:
BG7 module connectors for a description of the rear-panel connectors. (See
page 2-11.)
BG7 module functional check for a basic procedure to check that the module
is functional. (See page 1-24.)
TG8000 Specifications and Performance Verification Technical Reference for
module specifications and for a detailed procedure to verify that the module
is functioning as specified.
TG8000 Programmer Manual for information about the commands to
remotely control the module.
The BG7 Black Generator module is a multiformat black generator with the
following features:
Four outputs for NTSC (with or without setup) or PAL black burst and HDTV
trilevel sync signals.
Individual format and timing control for each output.
Black burst with field ID and NTSC/PAL color bars signals output
(Option CB).
Full remote control using Ethernet interface.
Timecode generator with VITC when a GPS7 module is installed (the
BG7 module hardware must be version 1.2 or above).
NOTE.
PAL-M and PAL-N are not supported by the AGL7, ATG7 and
BG7 modules.
