ATG7 Analog Test Generator module

ATG7 module factory default settings

3–28
APL (Bounce): Outputs the High APL signal and Low APL signal alternately
for the period set in the PERIOD menu item.
Bounce: Outputs the 100% flat field signal and 0% flat field signal alternately
(regardless of the selected signal) for the period set in the PERIOD menu item.
PERIOD. Sets the time interval between two signals when they are output in
APL (Bounce) or Bounce mode. Use the left (◄) or right (►) arrow button to
change the interval. You can set the value from 0.5 seconds to 2.0 seconds in
0.5 second steps.
The following table shows the factory default settings for the ATG7 module.
These settings are recalled when you select Factory Default from the PRESET :
RECALL menu item in the mainframe main menu.

Table 3-7: ATG7 module factory default settings

Menu item name
STATUS (Shows the signal format and
signal name output from the SIGNAL
connector)
OUTPUT : BLACK 1 and BLACK 2
FORMAT
SIGNAL
OUTPUT : BARS
FORMAT
SIGNAL
ID TEXT
Status
TIMING
Vertical
Horizontal
APL
Mode
Period
Settings
NTSC SMPTE Color Bars
NTSC
Black Burst
NTSC
SMPTE Color Bar
Disable
0 Line(s)
0.0000 msec
APL OFF
1.0 sec
