Tektronix TG8000 User Manual page 464

SDI7 Dual Channel SD/HD/3G SDI Video Generator module
Table 3-63: Dolby E generated formats – 25 Hz frame rate
Dolby E Dolby E
program level
8x1 Program 1
M1
–20 dBSF –20 dBFS
1.0 kHz
–18 dBSF –18 dBFS
1.0 kHz
Multitone –18 dBFS
125 Hz
7.1 Program 1
L
–20 dBSF –20 dBFS
1.0 kHz
–18 dBSF –18 dBFS
1.0 kHz
Multitone –18 dBFS
250 Hz
5.1+2 Program 1
L
–20 dBSF –20 dBFS
1.0 kHz
–18 dBSF –18 dBFS
1.0 kHz
Multitone –18 dBFS
250 Hz
5.1 Program 1
L
–20 dBSF –20 dBFS
1.0 kHz
–18 dBSF –18 dBFS
1.0 kHz
Multitone –18 dBFS
250 Hz
4x2 Program 1
L1
–20 dBSF –20 dBFS
1.0 kHz
–18 dBSF –18 dBFS
1.0 kHz
Multitone –18 dBFS
125 Hz
3–314
Signal levels and frequencies
Program 2 Program 3
M2 M3
–20 dBFS –20 dBFS
1.0 kHz 1.0 kHz
–18 dBFS –18 dBFS
1.0 kHz 1.0 kHz
–20 dBFS –22 dBFS
250 Hz 350 Hz
Program 1 Program 1
C R
–20 dBFS –20 dBFS
1.0 kHz 1.0 kHz
–18 dBFS –18 dBFS
1.0 kHz 1.0 kHz
–20 dBFS –22 dBFS
350 Hz 475 Hz
Program 1 Program 1
C R
–20 dBFS –20 dBFS
1.0 kHz 1.0 kHz
–18 dBFS –18 dBFS
1.0 kHz 1.0 kHz
–20 dBFS –22 dBFS
350 Hz 475 Hz
Program 1 Program 1
C R
–20 dBFS –20 dBFS
1.0 kHz 1.0 kHz
–18 dBFS –18 dBFS
1.0 kHz 1.0 kHz
–20 dBFS –22 dBFS
350 Hz 475 Hz
Program 1 Program 2
R1 L2
–20 dBFS –20 dBFS
1.0 kHz 1.0 kHz
–18 dBFS –18 dBFS
1.0 kHz 1.0 kHz
–20 dBFS –22 dBFS
250 Hz 350 Hz
Program 4 Program 5
M4 M5
–20 dBFS –20 dBFS
1.0 kHz 1.0 kHz
–18 dBFS –18 dBFS
1.0 kHz 1.0 kHz
–24 dBFS –26 dBFS
475 Hz 600 Hz
Program 1 Program 1
Ls Rs
–20 dBFS –20 dBFS
1.0 kHz 1.0 kHz
–18 dBFS –18 dBFS
1.0 kHz 1.0 kHz
–24 dBFS –26 dBFS
600 Hz 1200 Hz
Program 1 Program 1
Ls Rs
–20 dBFS –20 dBFS
1.0 kHz 1.0 kHz
–18 dBFS –18 dBFS
1.0 kHz 1.0 kHz
–24 dBFS –26 dBFS
600 Hz 1200 Hz
Program 1 Program 1
Ls Rs
–20 dBFS –20 dBFS
1.0 kHz 1.0 kHz
–18 dBFS –18 dBFS
1.0 kHz 1.0 kHz
–24 dBFS –26 dBFS
600 Hz 1200 Hz
Program 2 Program 3
R2 L3
–20 dBFS –20 dBFS
1.0 kHz 1.0 kHz
–18 dBFS –18 dBFS
1.0 kHz 1.0 kHz
–24 dBFS –26 dBFS
475 Hz 600 Hz
TG8000 Multiformat Test Signal Generator User Manual
Program 6 Program 7 Program 8
M6 M7
–20 dBFS –20 dBFS –20 dBFS
1.0 kHz 1.0 kHz 1.0 kHz
–18 dBFS –18 dBFS –18 dBFS
1.0 kHz 1.0 kHz 1.0 kHz
–28 dBFS –30 dBFS –32 dBFS
1200 Hz 1800 Hz 2400 Hz
Program 1 Program 1 Program 1
LFE Lb
–20 dBFS –20 dBFS –20 dBFS
240 Hz 1.0 kHz 1.0 kHz
–18 dBFS –18 dBFS –18 dBFS
240 Hz 1.0 kHz 1.0 kHz
–28 dBFS –30 dBFS –32 dBFS
125 Hz 1800 Hz 2400 Hz
Program 1 Program 1 Program 1
LFE Lt
–20 dBFS –20 dBFS –20 dBFS
240 Hz 1.0 kHz 1.0 kHz
–18 dBFS –18 dBFS –18 dBFS
240 Hz 1.0 kHz 1.0 kHz
–28 dBFS –30 dBFS –32 dBFS
125 Hz 1800 Hz 2400 Hz
Program 1
LFE
–20 dBFS
240 Hz
–18 dBFS
240 Hz
–28 dBFS
125 Hz
Program 3 Program 4 Program 4
R3 L4
–20 dBFS –20 dBFS –20 dBFS
1.0 kHz 1.0 kHz 1.0 kHz
–18 dBFS –18 dBFS –18 dBFS
1.0 kHz 1.0 kHz 1.0 kHz
–28 dBFS –30 dBFS –32 dBFS
1200 Hz 1800 Hz 2400 Hz
M8
Rb
Rt
R4
