DVG7 module main menu

TG8000 Multiformat Test Signal Generator User Manual
Table 3-17: DVG7 module signal set assigned to the test signal buttons (cont.)
Button name Signal set
SDI SDI Test
OTHER Other
625-270 format
COLOR BAR Color Bars
LINEARITY Linearity
FLAT FIELD Flat Fields
Multi Burst
MULTI BURST
SWEEP Sweep
MONITOR Monitor
PULSE BAR Pulse & Bar
Timing
TIMING
SDI SDI Test
OTHER Other
Use the DVG7 module main menu to perform the following tasks:
Set the logo, text, or circle overlay on the output signal.
Set the timing offset on the output signals.
Scroll the active picture area of the output signal.
Enable or disable the output and set parameters for each embedded audio
group.
Enable or disable the video output signal.
DVG7 Digital Video Generator module
Signals in the signal set
Equalizer Test, PLL Test, SDI Matrix
Chroma Freq. Resp., Color Palette, FCC
Composite, FCC Multiburst, NTC7 Combination,
NTC7 Composite
100% Colour Bars, 75% Colour Bars, 100% Colour
Bars Over Red, 75% Colour Bars Over Red
10 Step, 3 Channel Ramp, 5 Step, B-Y Valid Ramp,
Limit Ramp, Modulated Ramp, Oversize Ramp,
R-Y Valid Ramp, Shallow Ramp, Shallow Ramp
Matrix, Y Valid Ramp
0% Flat Field, 100% Flat Field, 50% Flat Field, Field
Square Wave
60% Multiburst
100% Sweep, 60% Sweep, SinX/X
100% Red Field, 2 Level Ped. & Pluge, 4 Level Ped.
& Pluge, 75% Red Field, Convergence Pattern,
Gamut Test, Grey Window, White Window
2T 4T 10T Pulse & Bar, 2T 4T 20T Pulse & Bar
2.5 MHz Bowtie, 500 kHz Bowtie, Active Picture
Timing, Co-Siting Pulse
Equalizer Test, PLL Test, SDI Matrix
CCIR 17, CCIR 18, CCIR 330, CCIR 331,
CCIR 331 G2
3–79
