Table 3-59: SDI7 module signal sets assigned to the test signal buttons (cont.)
Button name Signals in the signal set
FLAT FIELD 0% Flat Field (Black),
50% Flat Field,
100% Flat Field (White)
100% Red Field, 100% Green Field,
100% Blue Field, 100% Cyan Field,
100% Magenta Field, 100% Yellow Field
10% Flat Field, 20% Flat Field,
30% Flat Field, 40% Flat Field,
60% Flat Field, 70% Flat Field,
80% Flat Field, 90% Flat Field
75% Red Field, 75% Green Field,
75% Blue Field, 75% Cyan Field,
75% Magenta Field, 75% Yellow Field
Black to White-1, Black to White-2,
Black to White-3, Black to White-4,
Black to White-5, Black to White-6,
Black to White-7, Black to White-8,
Black to White-9, Black to White-10,
Black to Gray-1, Black to Gray-2,
Black to Gray-3, Black to Gray-4,
Black to Gray-5, Black to Gray-6,
Black to Gray-7, Black to Gray-8,
Black to Gray-9, Black to Gray-10
Red-1 Field, Red-2 Field,
Green-1 Field, Green-2 Field,
Blue-1 Field, Blue-2 Field,
Cyan-1 Field, Cyan-2 Field,
Magenta-1 Field, Magenta-2 Field,
Yellow-1 Field, Yellow-2 Field
TG8000 Multiformat Test Signal Generator User Manual
SDI7 Dual Channel SD/HD/3G SDI Video Generator module
Description
Full-frame monochrome flat fields. The factory installed patterns
include 0% (black), 50%, and 100% (white).
You can install extended signal sets, which include additional
patterns for the remaining 10% increments. (See page 3-268, To
install the enhanced signal sets on the SDI7 module.)
Full-frame color flat fields. The factory installed patterns include
each of six colors (red, green, blue, cyan, magenta, and yellow)
at 100% value.
You can install enhanced signal sets, which include additional
patterns for these six colors at 75% value. (See page 3-268, To
install the enhanced signal sets on the SDI7 module.)
Full-frame monochrome flat fields available in individual patterns
from 10% to 90% in 10% increments.
These signals are not part of the factory installed signal sets. You
must install the enhanced signal sets to access these signals.
(See page 3-268, To install the enhanced signal sets on the SDI7
module.)
Full-frame color flat fields available in individual patterns of 75%
value for each of six colors (red, green, blue, cyan, magenta, and
yellow).
These signals are not part of the factory installed signal sets. You
must install the enhanced signal sets to access these signals.
(See page 3-268, To install the enhanced signal sets on the SDI7
module.)
Full-frame monochrome flat fields representing the individual
steps in the SMPTE EG 432–1 step-scale patterns available under
the MONITOR button.
These signals are not part of the factory installed signal sets. You
must install the enhanced signal sets to access these signals.
(See page 3-268, To install the enhanced signal sets on the SDI7
module.)
Full-frame color flat fields representing the individual colors in
the SMPTE EG 432–1 color-accuracy patterns available under
the COLOR BAR button.
These signals are not part of the factory installed signal sets. You
must install the enhanced signal sets to access these signals.
(See page 3-268, To install the enhanced signal sets on the SDI7
module.)
3–263
