AG7 Audio Generator module

AG7 module product description

TG8000 Multiformat Test Signal Generator User Manual
This section describes the module-specific functions of the AG7 Audio Generator
module. Refer to the following locations for additional information about the
module:
AG7 module connectors for a description of the rear-panel connectors. (See
page 2-7.)
AG7 module functional check for a basic procedure to check that the module
is functional. (See page 1-16.)
TG8000 Specifications and Performance Verification Technical Reference for
module specifications and for a detailed procedure to verify that the module
is functioning as specified.
TG8000 Programmer Manual for information about the commands to
remotely control the module.
The AG7 Audio Generator module can output serial digital audio signals that
comply with the AES/EBU standard. The module contains the following features:
8 channels (4 AES/EBU audio pairs) of serial digital audio outputs with 24
or 20 bits resolution
Adjustable frequencies, amplitudes, and audio clicks in every channel
Silence and 48 kHz clock (word clock) outputs
Full remote control using Ethernet interface
The module also supports the following audio frequencies:
Silence 500 Hz
50 Hz 600 Hz
100 Hz 750 Hz
150 Hz 800 Hz
200 Hz 1000 Hz
250 Hz 4000 Hz
1200 Hz
300 Hz
400 Hz 1500 Hz
2000 Hz 8000 Hz
2400 Hz 9600 Hz
3000 Hz 10000 Hz
3200 Hz 12000 Hz
4800 Hz 15000 Hz
5000 Hz 16000 Hz
6000 Hz 20000 Hz
1600 Hz
