HDLG7 module factory default settings

TG8000 Multiformat Test Signal Generator User Manual
H Step. Sets the number of samples to be scrolled per frame set in the Period
menu item. Use the left (◄) or right (►) arrow button to change the value. You
can set the value from -252 to +252 in 4-sample steps.
V Step. Sets the number of lines to be scrolled per frame set in the Period menu
item. Use the left (◄) or right (►) arrow button to change the value. You can set
the value from -252 to +252 in 1-line steps.
Period. Sets the time interval between occurrences of the scrolling. Use the left
(◄) or right (►) arrow button to change the value. You can set the value from 1
to 16 in 1-frame steps.
Random. Sets whether or not the picture scrolls randomly. Use the left (◄) or
right (►) arrow button to select between Disable and Enable. Press the ENTER
button to confirm the selection.
The following table shows the factory default settings for the HDLG7 module.
These settings are recalled when you select Factory Default from the PRESET :
RECALL menu item in the mainframe main menu.
NOTE.
The factory default settings put the HDLG7 module in the Generator mode.
Table 3-44: HDLG7 module factory default settings
Menu item name
STATUS
SAMPLE STRUCTURE/DEPTH
ALPHA CHANNEL DATA
LINK OFFSET
2K TEST SIGNAL KEY ASSIGN
MOVING PICTURE
H Step
V Step
Period
Random
Converter mode
Converter embedded audio
2K Horizontal/Vertical Gradient offset
Horizontal Gradient offset
Vertical Gradient offset
HDLG7 HD Dual Link Video Generator module
Settings
SMPTE RP219 Color Bars 1080 59.94i GBR 4:4:4
12 bits
1080 GBR 4:4:4 12 bits
Use Y/G Channel
0.0000 ms
HD Test Signal
0 Sample(s)
0 Line(s)
1 Frame(s)
Disable
Normal
LINK A
16
16
3–227
