TG8000 Multiformat Test Signal Generator User Manual
Amplitude: Use this menu to set the audio amplitude from –60 dBFS to
0 dBFS, in steps of 1 dBFS. Use the left (◄) and right (►) arrow buttons to
set the amplitude, and then press the ENTER button to confirm it.
Audio Click: Use this menu to set the audio click rate to one click every one,
two, three, or four seconds, or turn the click off. Use the left (◄) or right (►)
arrow button to select the click rate, and then press the ENTER button to
confirm the selection.
Channel Origin: Use this menu to set a channel origin ID of up to four
ASCII characters. Use the left (◄) and right (►) arrow buttons to position
the cursor, and then use the up (▲) and down (▼) arrow buttons to set the ID.
Press the ENTER button to confirm the Channel Origin ID.
Sampling. Use this menu to set the sampling alignment status bits for the
selected audio group's Audio Control Packet (ACP). Use the left (◄) or right (►)
arrow button to select between Frame, Frame without Frame Number, and
Asynchronous. Press the ENTER button to confirm the selection.
HD3G7 HD 3 Gb/s SDI Video Generator module
3–195
