Y. Turns the Y component of the serial digital video signals on or off. Use the
left (◄) or right (►) arrow button to select between ON and OFF. Press the
ENTER button to confirm the selection.
Pb. Turns the Pb component of the serial digital video signals on or off. Use the
left (◄) or right (►) arrow button to select between ON and OFF. Press the
ENTER button to confirm the selection.
Pr. Turns the Pr component of the serial digital video signals on or off. Use the
left (◄) or right (►) arrow button to select between ON and OFF. Press the
ENTER button to confirm the selection.
Resolution. Sets the resolution of the serial digital video signals. Use the left (◄)
or right (►) arrow button to select between 10 bits and 8 bits. Press the ENTER
button to confirm the selection.
EDH. Turns the insertion of the EDH (Error Detection and Handling) information
on or off on the serial digital video signals. Use the left (◄) or right (►) arrow
button to select between ON and OFF. Press the ENTER button to confirm the
selection.
AV timing mode. Turns the output mode for an audio/video timing measurement
on or off. Use the left (◄) or right (►) arrow button to select between ON and
OFF. Press the ENTER button to confirm the selection.
When you turn this mode on, the specified audio and video signals are
synchronously on for 0.5 second and off for 4.5 seconds. With this signal, you can
measure the time delay that accumulates between the audio and video content of
the television signal during signal transport. The time delay can be measured by a
video analyzer with the serial digital video signal or by an oscilloscope with the
analog audio and video signals extracted from the serial digital video signal.
The following settings are recommended for the audio and video signals when
you use this mode:
Audio signal (CH1 and CH2 of Group 1): 10000 Hz, -20 dBFS
Video signal: 100% Flat Field
NOTE.
The AV Timing Mode setting is not saved as a preset.
