GPS7 GPS Synchronization and Timecode module
3–156
Table 3-24: GPS7 module factory default settings (cont.)
Submenu
Menu item name item name
TIME SETUP
SELECT
MENU
SELECT LTC
LTC 1 INPUT-OUTPUT
(LTC 1 only)
LTC 2
LTC 3
LTC 4
TYPE
SOURCE
OFFSET
TIMING
OUTPUT
LEVEL
SELECT GPIO
INPUT 1
OUTPUT 1
OUTPUT 2
Settings
TIME OF DAY menu
Source: GPS Signal
Internal: 2008-01-01 00:00:00
TIME ZONE OFFSET menu
+ 00:00
DST SCHEDULE menu
Enable: Off
PROGRAM TIME menu
Setup: Initial Time: 00:00:00
JAM SYNC menu
Enable: ON
LEAP SECOND menu
Setup: Scheduled Time: 00:00:00
ALARM TIME menu
Enable: Off
Setup: Alarm Time: 00:00:00
ALARM DELAY menu
GPO Loss of Lock: 00:00:10
GPO Signal Warning: 00:00:10
Black 2 Blank On Unlock: 00:00:10
Output (if allowed)
NOTE.
INPUT-OUTPUT selection for LTC 1 is
not available on earlier GPS7 modules without the
REF IN input connector.
30 fps drop frame
Local (DST)
+ 00:00:00:00
Delay: 0.00 ms
Level: 2.0 Volt
Trigger Select: None
Alarm Select: None
