TG8000 Multiformat Test Signal Generator User Manual
X position. Sets the horizontal position of the text. The position is set as a
percentage of active picture width. Use the left (◄) or right (►) arrow button to
change the position. You can set the value from 0.0% to 100.0% in 1% steps.
Y position. Sets the vertical position of the text. The position is set as a percentage
of active picture height. Use the left (◄) or right (►) arrow button to change the
position. You can set the value from 0.0% to 100.0% in 1% steps.
EDIT. Edits the text you want to display on the output test signal. Perform the
following steps to edit the text:
NOTE.
You can use up to 30 characters for the logo text. Use the blank character
to erase unneeded character(s).
1. Use the left (◄) or right (►) arrow button to select EDIT, and then press the
ENTER button to enable the text edit mode.
2. Use the left (◄) or right (►) arrow button to move the underscore character
( _ ) to the character you want to change.
3. Use the up (▲) or down (▼) arrow button to select the desired character.
4. After you enter all of the desired characters, press the ENTER button to exit
the text editing mode.
5. Use the left (◄) or right (►) arrow button to select SAVE, and then press the
ENTER button to save the text and its position to the signal file.
SAVE. Saves the text and its position to the signal file currently being output.
Press the ENTER button to save the text and its position to the signal file.
AVG7 Analog Video Generator module
3–41
