ATG7 Analog Test Generator module

How to operate the ATG7 module

3–18
After the ATG7 module is installed in the mainframe, and the mainframe is
installed in the rack or other location where it will be used, use the following
procedure to access each function of the module:
1. Connect the power cord to the power connector on the rear panel, and then
plug the cord into the AC electric power source. Electric power is supplied
to the mainframe.
2. Wait until the power-on initialization process is complete, and then check that
there are no error messages on the display.
3. After the initialization process is complete, the mainframe main menu appears
as shown below.
4. Press the front-panel MODULE button until the ATG7 module main menu
appears as shown below.
5. Select the signal format and the test signal that you want to output from the
SIGNAL connector. (See page 3-19, To select an output signal on the ATG7
module.)
6. Use the front-panel arrow buttons to navigate and select items in the main
menu and submenus to select the signal format and test signal you want to
output from the BLACK 1, BLACK 2, and BARS connectors, and to set
the other output parameters.
Refer to ATG7 Module Main Menu for detailed information about the main menu
and the submenu items. (See page 3-21.)
